3-1825059 Series

Catalog

SWITCH STANDARD DIP SPST

Part	Number of Positions	Actuator Type	Mounting Type	Circuit	Actuator Level	Current Rating (Amps)	Termination Style	Pitch [x]	Pitch	Pitch [x]	Electrical Life	Contact Material	Features	Operating Temperature [Min]	Operating Temperature [Max]	Mechanical Life	Contact Finish	Voltage Rating	Length [x]	Length [x]	Body Material	Height Above Board	Height Above Board	Length	Length
TE Connectivity Raychem Cable Protection 3-1825059-1	7	Standard	Surface Mount	SPST	Flush Recessed
TE Connectivity Raychem Cable Protection 3-1825059-0	6	Slide (Standard)	Surface Mount	SPST	Flush Recessed	25 mA	Gull Wing	0.1 in	Full	2.54 mm	1000 Cycles	Copper Alloy	Tape Seal	-30 ░C	85 °C	1000 Cycles	Gold	24 VDC	0.678 in	17.22 mm	Polyphenylene Sulfide (PPS)	0.177 in	4.5 mm
TE Connectivity Raychem Cable Protection 3-1825059-7	8	Slide (Standard)	Surface Mount	SPST	Flush Recessed	25 mA	Gull Wing	0.1 in	Full	2.54 mm	1000 Cycles	Copper Alloy		-30 ░C	85 °C	1000 Cycles	Gold	24 VDC			Polyphenylene Sulfide (PPS)	0.177 in	4.5 mm	22.3 mm	0.878 in
