CP20 Series
Manufacturer: PULS, LP
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
AC/DC DIN RAIL SUPPLY 24V 480W
| Part | Current - Output (Max) | Input Type | Standard Number | Power (Watts) | Number of Outputs | DC Voltage - Input (Min) | Operating Temperature (Max) | Operating Temperature (Min) | Size / Dimension Length | Size / Dimension Width | Size / Dimension Height | Applications | Voltage - Isolation | Voltage - Output 1 | DC Voltage - Input (Max) | Features | Efficiency | Approval Agency | AC Voltage - Input (Max) | AC Voltage - Input (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 PULS, LP | 20 A | AC AC or DC DC | 61010-2-201 | 480 W | 1 | 110 V | 70 °C | -25 °C | 5 in | 1.89 in | 4.88 in | Industrial ITE (Commercial) | 500 V | 24 V | 150 V | Adjustable Output IP20 Load Sharing PFC Universal Input | 94.2 % | EAC IEC UL | 264 VAC | 85 VAC |
 PULS, LP | 20 A | AC AC or DC DC | 61010-2-201 Class I Div 2 | 480 W | 1 | 110 V | 70 °C | -25 °C | 5 in | 1.89 in | 4.88 in | Industrial ITE (Commercial) | 500 V | 24 V | 150 V | Adjustable Output IP20 Load Sharing PFC Universal Input | 94.2 % | ATEX EAC IEC IECEx UL | 264 VAC | 85 VAC |
 PULS, LP | 20 A | AC AC or DC DC | 61010-2-201 Class I Div 2 | 480 W | 1 | 110 V | 70 °C | -25 °C | 5 in | 1.89 in | 4.88 in | Hazardous Locations ITE (Commercial) | 24 V | 150 V | Adjustable Output PFC Universal Input | 95.6 % | ATEX EAC IEC IECEx UL | 264 VAC | 85 VAC | |
 PULS, LP | 20 A | AC AC or DC DC | 61010-2-201 Class I Div 2 | 480 W | 1 | 88 V | 70 °C | -25 °C | 5 in | 1.89 in | 4.88 in | Hazardous Locations Industrial ITE (Commercial) | 24 V | 180 V | Adjustable Output PFC Universal Input | 95.2 % | ATEX EAC IEC IECEx UL | 264 VAC | 85 VAC | |
 PULS, LP | 20 A | AC AC or DC DC | 61010-2-201 Class I Div 2 | 480 W | 1 | 88 V | 70 °C | -25 °C | 5 in | 1.89 in | 4.88 in | Hazardous Locations Industrial ITE (Commercial) | 24 V | 180 V | Adjustable Output PFC Remote On/Off Universal Input | 95.6 % | ATEX EAC IEC IECEx UL | 264 VAC | 85 VAC | |
 PULS, LP | 20 A | AC AC or DC DC | 480 W | 1 | 110 V | 70 °C | -40 °C | 5 in | 1.89 in | 4.88 in | Industrial ITE (Commercial) | 500 V | 24 V | 150 V | Adjustable Output IP20 Load Sharing PFC Universal Input | 93.8 % | CE cULus EAC | 264 VAC | 85 VAC | |
 PULS, LP | 20 A | AC AC or DC DC | 61010-2-201 Class I Div 2 | 480 W | 1 | 88 V | 70 °C | -25 °C | 5 in | 1.89 in | 4.88 in | Hazardous Locations Industrial ITE (Commercial) | 24 V | 180 V | Adjustable Output PFC Universal Input | 95.6 % | ATEX EAC IEC IECEx UL | 264 VAC | 85 VAC | |
 PULS, LP | 20 A | AC AC or DC DC | 61010-2-201 Class I Div 2 | 480 W | 1 | 88 V | 70 °C | -25 °C | 5 in | 1.89 in | 4.88 in | Hazardous Locations Industrial ITE (Commercial) | 24 V | 180 V | Adjustable Output PFC Universal Input | 95.2 % | ATEX EAC IEC IECEx UL | 264 VAC | 85 VAC | |
 PULS, LP | 20 A | AC AC or DC DC | 61010-2-201 Class I Div 2 | 480 W | 1 | 88 V | 70 °C | -25 °C | 5 in | 1.89 in | 4.88 in | Hazardous Locations Industrial ITE (Commercial) | 3 kV | 24 V | 180 V | Adjustable Output PFC Universal Input | 95.6 % | ATEX EAC IEC IECEx UL | 264 VAC | 85 VAC |
