X2 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

HEATSHRINK 3.6MM DIA 1=5M BK

Part	Length	Length	Length [x]	Length [x]	Recovered Wall Thickness	Recovered Wall Thickness	Shrinkage Ratio [Min]	Shrinkage Ratio [Max]	Storage/Refrigeration Temperature [Max]	Storage/Refrigeration Temperature [Max]	Storage/Refrigeration Temperature [Min]	Storage/Refrigeration Temperature [Min]	Color	Shelf Life	Operating Temperature [Max]	Operating Temperature [Min]	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Material	Features	Type	Shrink Temperature	Length	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Spool Size [x]	Spool Size [x]
TE Connectivity AMP Connectors X2-3.0-0-SP	1 m 200 m	3.28 ft 656.2 ft	16.4 ft	5 m	0.43 mm	0.017 in	1	2	95 °F	35 °C	65 °F	18 °C	Black	144 Months	125 °C	-30 ░C	1.52 mm	0.06 in	Polyolefin (PO) Irradiated Halogen Free	Abrasion Resistant Flame Retardant	Tubing Flexible	70 °C
TE Connectivity AMP Connectors X2-1.0-0-SP-SM	200 m	656.2 ft			0.43 mm	0.017 in	1	2	95 °F	35 °C	65 °F	18 °C	Black	144 Months	125 °C	-30 ░C	0.51 mm	0.02 in	Polyolefin (PO) Irradiated Halogen Free	Abrasion Resistant Flame Retardant	Tubing Flexible	70 °C	Enter Number of Meters in Order Quantity	0.059 in	1.5 mm
TE Connectivity AMP Connectors X2-16.0-0-FSP-SM	1 m 10 m 25 m 50 m	3.28 ft 32.8 ft 82 ft 164 ft	16.4 ft	5 m	0.69 mm	0.027 in	1	2	95 °F	35 °C	65 °F	18 °C	Black	144 Months	125 °C	-30 ░C	8 mm	0.315 in	Polyolefin (PO) Irradiated Halogen Free	Abrasion Resistant Flame Retardant	Tubing Flexible	70 °C	Enter Number of Meters in Order Quantity	0.665 in	16.89 mm	164 '	50 m
TE Connectivity AMP Connectors X2-9.0-0-FSP	50 m	164 ft			0.56 mm	0.022 in	1	2	95 °F	35 °C	65 °F	18 °C	Black	144 Months	125 °C	-30 ░C	4.52 mm	0.178 "	Polyolefin (PO) Irradiated Halogen Free	Abrasion Resistant Flame Retardant	Tubing Flexible	70 °C		0.378 in	9.6 mm
TE Connectivity AMP Connectors X2-8.0-0-FSP	1 m 50 m	3.28 ft 164 ft			0.56 mm	0.022 in	1	2	95 °F	35 °C	65 °F	18 °C	Black	144 Months	125 °C	-30 ░C	3.99 mm	0.157 "	Polyolefin (PO) Irradiated Halogen Free	Abrasion Resistant Flame Retardant	Tubing Flexible	70 °C		0.339 in	8.61 mm
TE Connectivity AMP Connectors X2-10.0-0-FSP	1 m 50 m	3.28 ft 164 ft	16.4 ft	5 m	0.56 mm	0.022 in	1	2	95 °F	35 °C	65 °F	18 °C	Black	144 Months	125 °C	-30 ░C	5 mm	0.197 in	Polyolefin (PO) Irradiated Halogen Free	Abrasion Resistant Flame Retardant	Tubing Flexible	70 °C		0.409 in	10.39 mm
TE Connectivity AMP Connectors X2-3.5-0-SP	1 m 200 m	3.28 ft 656.2 ft	16.4 ft	5 m	0.46 mm	0.018 "	1	2	95 °F	35 °C	65 °F	18 °C	Black	144 Months	125 °C	-30 ░C	1.75 mm	0.069 in	Polyolefin (PO) Irradiated Halogen Free	Abrasion Resistant Flame Retardant	Tubing Flexible	70 °C		0.161 in	4.09 mm
TE Connectivity AMP Connectors X2-11.0-0-FSP-SM	1 m 10 m 25 m 50 m	3.28 ft 32.8 ft 82 ft 164 ft	16.4 ft	5 m	0.56 mm	0.022 in	1	2	95 °F	35 °C	65 °F	18 °C	Black	144 Months	125 °C	-30 ░C	5.51 mm	0.217 in	Polyolefin (PO) Irradiated Halogen Free	Abrasion Resistant Flame Retardant	Tubing Flexible	70 °C	Enter Number of Meters in Order Quantity	0.449 "	11.41 mm	164 '	50 m
TE Connectivity AMP Connectors X2-25.0-0-FSP-SM	1 m 10 m 25 m 50 m	3.28 ft 32.8 ft 82 ft 164 ft	16.4 ft	5 m	0.76 mm	0.03 in	1	2	95 °F	35 °C	65 °F	18 °C	Black	144 Months	125 °C	-30 ░C	12.5 mm	0.492 in	Polyolefin (PO) Irradiated Halogen Free	Abrasion Resistant Flame Retardant	Tubing Flexible	70 °C		1.063 in	27 mm
TE Connectivity AMP Connectors X2-8.0-0-FSP-SM	50 m	164 ft			0.56 mm	0.022 in	1	2	95 °F	35 °C	65 °F	18 °C	Black	144 Months	125 °C	-30 ░C	3.99 mm	0.157 "	Polyolefin (PO) Irradiated Halogen Free	Abrasion Resistant Flame Retardant	Tubing Flexible	70 °C	Enter Number of Meters in Order Quantity	0.339 in	8.61 mm	164 '	50 m
