CPE5R48 Series
Manufacturer: Semiconductor Circuits, Inc.
Beta
⌘K
DC DC CONVERTER 29.8V 149W
| Part | Type | Features | Current - Output (Max) [Max] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Number of Outputs | Voltage - Output 1 | Voltage - Isolation | Supplier Device Package | Power (Watts) | Applications | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Input (Max) [Max] | Package / Case | Mounting Type | Voltage - Input (Min) [Min] | Control Features | Approval Agency | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Semiconductor Circuits, Inc. | Isolated Module | Adjustable Output Remote On/Off Remote Sense | 5 A | 11.8 mm | 2.3 in | 22.9 mm | 0.9 " | 58.4 mm | 0.46 in | 1 | 29.8 V | 2250 VDC | Eighth Brick | 149 W | ITE (Commercial) | 85 °C | -40 °C | 75 V | Eighth Brick | Through Hole | 36 V | Active Low Enable | CSA TUV UL | 93 % |
