DPID24 Series

Catalog

SSR RELAY, DUAL, PANEL MOUNT, PU

Part	Voltage - Input [Max]	Voltage - Input [Min]	Termination Style	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Load Current	Output Type	Voltage - Load [Min]	Voltage - Load [Max]	Circuit
Sensata-Crydom DPID2440R	32 VDC	4 V	Screw Terminal	80 °C	-40 C	Chassis Mount	40 A	AC	24 V	280 V	SPST-NO (1 Form A) x 2
Sensata-Crydom DPID2440	32 VDC	4 V	Screw Terminal	80 °C	-40 C	Chassis Mount	40 A	AC Zero Cross	24 V	280 V	SPST-NO (1 Form A) x 2
Sensata-Crydom DPID2420RH	32 VDC	4 V	Screw Terminal	80 °C	-40 C	Chassis Mount	20 A	AC	24 V	280 V	SPST-NO (1 Form A) x 2
Sensata-Crydom DPID2440RH	32 VDC	4 V	Screw Terminal	80 °C	-40 C	Chassis Mount	40 A	AC	24 V	280 V	SPST-NO (1 Form A) x 2
Sensata-Crydom DPID2420H	32 VDC	4 V	Screw Terminal	80 °C	-40 C	Chassis Mount	20 A	AC Zero Cross	24 V	280 V	SPST-NO (1 Form A) x 2
Sensata-Crydom DPID2420	32 VDC	4 V	Screw Terminal	80 °C	-40 C	Chassis Mount	20 A	AC Zero Cross	24 V	280 V	SPST-NO (1 Form A) x 2
Sensata-Crydom DPID2440H	32 VDC	4 V	Screw Terminal	80 °C	-40 C	Chassis Mount	40 A	AC Zero Cross	24 V	280 V	SPST-NO (1 Form A) x 2
Sensata-Crydom DPID2420R	32 VDC	4 V	Screw Terminal	80 °C	-40 C	Chassis Mount	20 A	AC	24 V	280 V	SPST-NO (1 Form A) x 2
