16_QMA-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
RF COAX CONN, QMA, R/A PLUG, 50 OHM ROHS COMPLIANT: YES
| Part | Body Finish | Body Material | Center Contact Plating | Voltage Rating | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Number of Ports | Housing Color | Frequency - Max [Max] | Center Contact Material | Cable Group | Impedance | Connector Type | Fastening Type | Mounting Type | Contact Termination | Shield Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | White Bronze | Bronze | Gold | 480 V | 85 °C | -40 C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 1 | Silver | 18 GHz | Brass | RG-58 | 50 Ohms | Plug Male Pin | Push-Pull | Free Hanging (In-Line) Right Angle | Solder | Crimp |
 Huber+Suhner, Inc. | White Bronze | Bronze | Gold | 480 V | 85 °C | -40 C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 1 | Silver | 18 GHz | Brass | 188 316 RG-174 | 50 Ohms | Plug Male Pin | Push-Pull | Free Hanging (In-Line) Right Angle | Solder | Crimp |
 Huber+Suhner, Inc. | White Bronze | Bronze | Gold | 480 V | 85 °C | -40 C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 1 | Silver | 18 GHz | Brass | 223 400 RG-142 | 50 Ohms | Plug Male Pin | Push-Pull | Free Hanging (In-Line) Right Angle | Solder | Crimp |
 Huber+Suhner, Inc. | Gold | Brass | Gold | 480 V | 105 ░C | -40 C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 1 | Gold | 18 GHz | Brass | RG-141 | 50 Ohms | Plug Male Pin | Snap-On | Free Hanging (In-Line) Right Angle | Solder | Solder |
 Huber+Suhner, Inc. | White Bronze | Bronze | Gold | 480 V | 85 °C | -40 C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 1 | Silver | 18 GHz | Brass | 223 400 RG-142 | 50 Ohms | Plug Male Pin | Push-Pull | Free Hanging (In-Line) Right Angle | Solder | Crimp |
 Huber+Suhner, Inc. | White Bronze | Bronze | Gold | 480 V | 85 °C | -40 C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 1 | Silver | 11 GHz | Brass | RG-405 (.086 Semi Rigid) | 50 Ohms | Plug Male Pin | Push-Pull | Free Hanging (In-Line) Right Angle | Solder | Solder |
Huber+Suhner, Inc. | White Bronze | Bronze | Gold | 480 V | 85 °C | -40 C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 1 | Silver | 18 GHz | Brass | 188 316 RG-174 | 50 Ohms | Plug Male Pin | Push-Pull | Free Hanging (In-Line) Right Angle | Solder | Crimp |
 Huber+Suhner, Inc. | Gold | Brass | Gold | 480 V | 105 ░C | -40 C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 1 | Gold | 18 GHz | Brass | RG-141 | 50 Ohms | Plug Male Pin | Snap-On | Free Hanging (In-Line) Right Angle | Solder | Solder |
Huber+Suhner, Inc. | Gold | 480 V | 105 ░C | -40 C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 1 | 18 GHz | Brass | 50 Ohms | Female Socket Jack | Threaded | Free Hanging (In-Line) Right Angle | Solder | Crimp | ||||
Huber+Suhner, Inc. | Gold | 480 V | 105 ░C | -40 C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 1 | 18 GHz | Brass | 50 Ohms | Female Socket Jack | Threaded | Free Hanging (In-Line) Right Angle | Solder | Crimp |
