SW RKR SPST
Description
AI
25A at 12V DC, 15A at 24V DC. Sealed to IP66 for water resistance. (high pressure wash.) Single Pole, Single Throw. Two brass blade terminals.
Beta
⌘K
SW RKR SPST
SW RKR SPST
| Part | Panel Cutout Dimensions [y] | Panel Cutout Dimensions [x] | Ingress Protection | Current Rating (Amps) | Color - Actuator/Cap | Actuator Type | Switch Function | Termination Style | Actuator Marking | Circuit | Mounting Type | Voltage Rating - DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Littelfuse/Commercial Vehicle Products | 21.08 mm | 36.83 mm | IP66 | 15 A | Black | Concave (Curved) | On-Off-On | Quick Connect - 0.250" (6.3mm) | No Marking | DPDT | Panel Mount Snap-In | 24 V |
 Littelfuse/Commercial Vehicle Products | 21.08 mm | 36.83 mm | IP66 | 15 A | Black | Concave (Curved) | On-Off | Quick Connect - 0.250" (6.3mm) | No Marking | DPST | Panel Mount Snap-In | 24 V |
Littelfuse/Commercial Vehicle Products | 21.08 mm | 36.83 mm | IP66 | 15 A | Black | Concave (Curved) | Mom-Off-Mom | Quick Connect - 0.250" (6.3mm) | No Marking | SPDT | Panel Mount Snap-In | 24 V |
 Littelfuse/Commercial Vehicle Products | 21.08 mm | 36.83 mm | IP66 | 15 A | Black | Concave (Curved) | On-Off | Quick Connect - 0.250" (6.3mm) | No Marking | SPST | Panel Mount Snap-In | 24 V |
 Littelfuse/Commercial Vehicle Products | 21.08 mm | 36.83 mm | IP66 | 15 A | Black | Concave (Curved) | Off-Mom | Quick Connect - 0.250" (6.3mm) | No Marking | SPST-NO | Panel Mount Snap-In | 24 V |
