833-040 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 40POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Positions | Flange Feature | Mounting Type | Number of Rows | Card Type | Contact Material | Contact Finish | Pitch | Pitch | Contact Type | Gender | Contact Finish Thickness | Contact Finish Thickness | Termination | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row [custom] | Color | Card Thickness [Max] | Card Thickness [Min] | Termination Rows [custom] | Number of Positions/Bay/Row | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 40 | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 1 | Non Specified - Single Edge | Copper Alloy | Gold | 3.96 mm | 0.156 in | Cantilever | Female | 0.25 Ám | 10 Áin | Wire Wrap | Single | 125 °C | -40 C | 40 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 40 | Through Hole | 1 | Non Specified - Single Edge | Copper Alloy | Gold | 3.96 mm | 0.156 in | Cantilever | Female | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Single | 125 °C | -40 C | 40 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 40 | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Non Specified - Dual Edge | Copper Alloy | Gold | 3.96 mm | 0.156 in | Cantilever | Female | 0.25 Ám | 10 Áin | Wire Wrap | Dual | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 20 Bay/Row | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 40 | Through Hole | Non Specified - Dual Edge | Copper Alloy | Gold | 3.96 mm | 0.156 in | Cantilever | Female | 0.25 Ám | 10 Áin | Wire Wrap | Dual | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 20 Bay/Row | 2 | 0.156 " | 3.96 mm | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 40 | Through Hole | Non Specified - Dual Edge | Copper Alloy | Gold | 3.96 mm | 0.156 in | Cantilever | Female | 0.25 Ám | 10 Áin | Solder | Dual | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 20 Bay/Row | 2 | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 40 | M3 Threaded Insert Top Mount Opening | Through Hole | 1 | Non Specified - Single Edge | Copper Alloy | Gold | 3.96 mm | 0.156 in | Cantilever | Female | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Single | 125 °C | -40 C | 40 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 40 | Through Hole | Non Specified - Dual Edge | Copper Alloy | Gold | 3.96 mm | 0.156 in | Cantilever | Female | 0.25 Ám | 10 Áin | Wire Wrap | Dual | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 20 Bay/Row | 2 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 40 | Right Angle Through Hole | Non Specified - Dual Edge | Copper Alloy | Gold | 3.96 mm | 0.156 in | Cantilever | Female | 0.25 Ám | 10 Áin | Solder | Dual | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 20 Bay/Row | 2 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 40 | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Non Specified - Dual Edge | Copper Alloy | Gold | 3.96 mm | 0.156 in | Cantilever | Female | 0.25 Ám | 10 Áin | Wire Wrap | Dual | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 20 Bay/Row | 2 | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 40 | Side Mount Opening Unthreaded | Through Hole | 1 | Non Specified - Single Edge | Copper Alloy | Gold | 3.96 mm | 0.156 in | Cantilever | Female | 0.25 Ám | 10 Áin | Solder | Single | 125 °C | -40 C | 40 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm |
