PEC02 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER R/A 2POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Post	Contact Shape	Fastening Type	Insulation Material	Number of Positions	Contact Length - Mating	Contact Length - Mating	Contact Type	Pitch - Mating	Pitch - Mating	Connector Type	Shrouding	Termination	Insulation Height	Insulation Height	Mounting Type	Contact Material	Number of Positions Loaded	Contact Length - Post	Contact Length - Post	Number of Rows	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Style	Current Rating (Amps)	Insulation Color	Material Flammability Rating	Number of Rows [custom]	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Overall Contact Length	Overall Contact Length	Insulation Height [z]	Insulation Height [z]
Sullins Connector Solutions PEC02SBDN	2.54 µm	100 µin	-65 ░C	125 °C	Tin	Square	Push-Pull	Polybutylene Terephthalate (PBT)	2	0.23 in	5.84 mm	Male Pin	0.1 "	2.54 mm	Header Breakaway	Unshrouded	Solder	3.56 mm	0.14 in	Right Angle Through Hole	Phosphor Bronze	All	10.16 mm	0.4 in	1	100 çin	2.54 çm	Board to Board Cable	3 A	Black	UL94 V-0
Sullins Connector Solutions PEC02DAEN	2.54 µm	100 µin	-65 ░C	125 °C	Tin	Square	Push-Pull	Polybutylene Terephthalate (PBT)	4	0.23 in	5.84 mm	Male Pin	0.1 "	2.54 mm	Header Breakaway	Unshrouded	Solder	2.54 mm	0.1 in	Through Hole	Phosphor Bronze	All	13.21 mm	0.52 in		100 çin	2.54 çm	Board to Board Cable	3 A	Black	UL94 V-0	2	0.1 in	2.54 mm	0.85 in	21.59 mm
Sullins Connector Solutions PEC02DFBN	2.54 µm	100 µin	-65 ░C	125 °C	Tin	Square	Push-Pull	Polybutylene Terephthalate (PBT)	4	0.318 in	8.08 mm	Male Pin	0.1 "	2.54 mm	Header Breakaway	Unshrouded	Solder	2.54 mm	0.1 in	Through Hole	Phosphor Bronze	All	5.58 mm	0.22 in		100 çin	2.54 çm	Board to Board Cable	3 A	Black	UL94 V-0	2	0.1 in	2.54 mm	0.638 in	16.21 mm
Sullins Connector Solutions PEC02SFBN	2.54 µm	100 µin	-65 ░C	125 °C	Tin	Square	Push-Pull	Polybutylene Terephthalate (PBT)	2	0.318 in	8.08 mm	Male Pin	0.1 "	2.54 mm	Header Breakaway	Unshrouded	Solder	2.54 mm	0.1 in	Through Hole	Phosphor Bronze	All	5.58 mm	0.22 in	1	100 çin	2.54 çm	Board to Board Cable	3 A	Black	UL94 V-0				0.638 in	16.21 mm
Sullins Connector Solutions PEC02DBEN	2.54 µm	100 µin	-65 ░C	125 °C	Tin	Square	Push-Pull	Polybutylene Terephthalate (PBT)	4	0.23 in	5.84 mm	Male Pin	0.1 "	2.54 mm	Header Breakaway	Unshrouded	Solder			Right Angle Through Hole	Phosphor Bronze	All	12.7 mm	0.5 "		100 çin	2.54 çm	Board to Board Cable	3 A	Black	UL94 V-0	2	0.1 in	2.54 mm			6.1 mm	0.24 in
Sullins Connector Solutions PEC02SBCN	2.54 µm	100 µin	-65 ░C	125 °C	Tin	Square	Push-Pull	Polybutylene Terephthalate (PBT)	2	0.23 in	5.84 mm	Male Pin	0.1 "	2.54 mm	Header Breakaway	Unshrouded	Solder	3.56 mm	0.14 in	Right Angle Through Hole	Phosphor Bronze	All	7.62 mm	0.3 in	1	100 çin	2.54 çm	Board to Board Cable	3 A	Black	UL94 V-0
Sullins Connector Solutions PEC02DBAN	2.54 µm	100 µin	-65 ░C	125 °C	Tin	Square	Push-Pull	Polybutylene Terephthalate (PBT)	4	0.23 in	5.84 mm	Male Pin	0.1 "	2.54 mm	Header Breakaway	Unshrouded	Solder			Right Angle Through Hole	Phosphor Bronze	All	2.54 mm	0.1 in		100 çin	2.54 çm	Board to Board Cable	3 A	Black	UL94 V-0	2	0.1 in	2.54 mm			6.1 mm	0.24 in
Sullins Connector Solutions PEC02DAHN	2.54 µm	100 µin	-65 ░C	125 °C	Tin	Square	Push-Pull	Polybutylene Terephthalate (PBT)	4	0.23 in	5.84 mm	Male Pin	0.1 "	2.54 mm	Header Breakaway	Unshrouded	Solder	2.54 mm	0.1 in	Through Hole	Phosphor Bronze	All	20.83 mm	0.82 in		100 çin	2.54 çm	Board to Board Cable	3 A	Black	UL94 V-0	2	0.1 in	2.54 mm	1.15 in	29.21 mm
Sullins Connector Solutions PEC02SFDN	2.54 µm	100 µin	-65 ░C	125 °C	Tin	Square	Push-Pull	Polybutylene Terephthalate (PBT)	2	0.318 in	8.08 mm	Male Pin	0.1 "	2.54 mm	Header Breakaway	Unshrouded	Solder	2.54 mm	0.1 in	Through Hole	Phosphor Bronze	All	10.67 mm	0.42 in	1	100 çin	2.54 çm	Board to Board Cable	3 A	Black	UL94 V-0				0.838 in	21.29 mm
Sullins Connector Solutions PEC02DABN	2.54 µm	100 µin	-65 ░C	125 °C	Tin	Square	Push-Pull	Polybutylene Terephthalate (PBT)	4	0.23 in	5.84 mm	Male Pin	0.1 "	2.54 mm	Header Breakaway	Unshrouded	Solder	2.54 mm	0.1 in	Through Hole	Phosphor Bronze	All	5.84 mm	0.23 "		100 çin	2.54 çm	Board to Board Cable	3 A	Black	UL94 V-0	2	0.1 in	2.54 mm	0.56 in	14.22 mm
