2301996 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN RJ-45 RCP 16 POS 1.27MM SOLDER RA THRU-HOLE 28 TERMINAL 2 PORT CAT 5 TRAY
| Part | Contact Finish | Applications | Housing Material | Orientation | Number of Ports | Shield Material | Mounting Type | Connector Type | Contact Material | LED Color | Number of Cores per Jack | Number of Rows | Height Above Board | Height Above Board | Operating Temperature [Max] | Operating Temperature [Min] | Tab Direction | Contact Finish Thickness | Contact Finish Thickness | Termination | Shielding |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Gold | 10/100/1000 Base-T AutoMDIX | Liquid Crystal Polymer (LCP) | 90 ° | 2 | Brass | Through Hole | RJ45 | Copper Alloy | Green Yellow | 8 | 1 | 0.531 in | 13.49 mm | 85 °C | -40 °C | Down | 0.76 Ám | 30 Áin | Solder | Shielded EMI Finger |
 TE Connectivity Raychem Cable Protection | Gold | 10/100 Base-T AutoMDIX | Liquid Crystal Polymer (LCP) | 90 ° | 2 | Brass | Through Hole | RJ45 | Copper Alloy | Green Yellow | 1 | 0.531 in | 13.49 mm | 85 °C | -40 °C | Down | 0.76 Ám | 30 Áin | Solder | Shielded EMI Finger | |
 TE Connectivity Raychem Cable Protection | Gold | 10/100 Base-T AutoMDIX | Liquid Crystal Polymer (LCP) | 90 ° | 2 | Brass | Through Hole | RJ45 | Copper Alloy | Green Yellow | 1 | 0.531 in | 13.49 mm | 85 °C | -40 °C | Up | 0.76 Ám | 30 Áin | Solder | Shielded EMI Finger | |
 TE Connectivity Raychem Cable Protection | Gold | 10/100 Base-T AutoMDIX | Liquid Crystal Polymer (LCP) | 90 ° | 2 | Brass | Through Hole | RJ45 | Copper Alloy | Does Not Contain LED | 1 | 0.531 in | 13.49 mm | 85 °C | -40 °C | Down | 0.76 Ám | 30 Áin | Solder | Shielded EMI Finger | |
 TE Connectivity Raychem Cable Protection | Gold | 10/100/1000 Base-T AutoMDIX | Liquid Crystal Polymer (LCP) | 90 ° | 2 | Brass | Through Hole | RJ45 | Copper Alloy | Green Yellow | 8 | 1 | 0.531 in | 13.49 mm | 85 °C | -40 °C | Up | 0.76 Ám | 30 Áin | Solder | Shielded EMI Finger |
 TE Connectivity Raychem Cable Protection | Gold | 10/100/1000 Base-T AutoMDIX | Liquid Crystal Polymer (LCP) | 90 ° | 2 | Brass | Through Hole | RJ45 | Copper Alloy | Does Not Contain LED | 8 | 1 | 0.531 in | 13.49 mm | 85 °C | -40 °C | Down | 0.76 Ám | 30 Áin | Solder | Shielded EMI Finger |
 TE Connectivity Raychem Cable Protection | Gold | 10/100 Base-T AutoMDIX | Liquid Crystal Polymer (LCP) | 90 ° | 2 | Brass | Through Hole | RJ45 | Copper Alloy | Green Yellow | 1 | 0.531 in | 13.49 mm | 85 °C | -40 °C | Down | 0.76 Ám | 30 Áin | Solder | Shielded EMI Finger | |
 TE Connectivity Raychem Cable Protection | Gold | 10/100/1000 Base-T AutoMDIX | Liquid Crystal Polymer (LCP) | 90 ° | 2 | Brass | Through Hole | RJ45 | Copper Alloy | Does Not Contain LED | 8 | 1 | 0.531 in | 13.49 mm | 85 °C | -40 °C | Down | 0.76 Ám | 30 Áin | Solder | Shielded EMI Finger |
