XZMOLA143 Series
Manufacturer: SunLED
Beta
⌘K
LED RED 625NM SMD
| Part | Thermal Resistance of Package | Voltage - Forward (Vf) (Typ) | Package / Case | Viewing Angle | Luminous Flux @ Current/Temperature | Mounting Type | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Current - Test | Lumens/Watt @ Current - Test | Wavelength | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Temperature - Test | Supplier Device Package | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SunLED | 60 °C/W | 2.5 V | Nonstandard SMD | 120 ° | 14 lm | Surface Mount | 5.3 mm | 0.209 " | 0.118 in | 3 mm | 150 mA | 37 lm/W | 625 nm | 1.02 mm | 0.04 in | 25 °C | SMD | Red |
