Barrier Terminal Blocks BARRIER BLOCK
Barrier Terminal Blocks BARRIER BLOCK
| Part | Bottom Termination | Pitch | Pitch | Barrier Type | Terminal Block Type | Current Rating (Amps) | Wire Gauge [Max] | Wire Gauge [Min] | Number of Circuits | Number of Wire Entries | Color | Top Termination | Voltage Rating | Features | Number of Rows [custom] | Material Flammability Rating | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Terminal Screw Material | Material - Insulation | Terminal Screw Finish | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Eaton - Electronics Division | Closed | 0.437 " | 11.1 mm | 2 Wall (Dual) | Barrier Block | 30 A | 22 AWG | 12 AWG | 6 | 12 | Black | Screws with Captive Plate | 300 VDC | Flange | 2 | ||||||||
 Eaton - Electronics Division | Closed | 0.437 " | 11.1 mm | 2 Wall (Dual) | Barrier Block | 30 A | 22 AWG | 12 AWG | 10 | 20 | Black | Screws with Captive Plate | 300 VDC | Flange | 2 | UL94 V-0 | 130 °C | -40 C | Chassis Panel | Brass | Thermoplastic | Nickel | |
Eaton - Electronics Division | Closed | 0.437 " | 11.1 mm | 2 Wall (Dual) | Barrier Block | 30 A | 22 AWG | 12 AWG | 10 | 20 | Black | Screws | 300 VDC | Flange | 2 | UL94 V-0 | 130 °C | -40 C | Chassis Panel | Steel | Thermoplastic | Zinc | |
 Eaton - Electronics Division | Closed | 0.437 " | 11.1 mm | 2 Wall (Dual) | Barrier Block | 20 A | 22 AWG | 12 AWG | 4 | 4 | Black | Screws with Quick Connect Tabs | 300 VDC | Flange | UL94 V-0 | 130 °C | -40 C | Chassis Panel | Thermoplastic | 1 | |||
 Eaton - Electronics Division | Closed | 0.437 " | 11.1 mm | 2 Wall (Dual) | Barrier Block | 30 A | 22 AWG | 12 AWG | 12 | Black | Screws with Quick Connect Tabs | 300 VDC | Flange | 2 |
