5006C Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 6COND 22AWG BLACK 1000'
| Part | Conductor Strand [custom] | Conductor Strand [custom] | Voltage | Cable Type | Usage | Length | Length | Jacket (Insulation) Material | Conductor Insulation | Ratings | Number of Conductors | Features | Conductor Material | Jacket Color | Operating Temperature [Min] | Operating Temperature [Max] | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Wire Gauge | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Length [x] | Length [x] | Spool Size | Spool Size | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | 30 AWG | 7 | 300 VDC | Multi-Conductor | Communication Control | 304.8 m | 1000 ft | Poly-Vinyl Chloride (PVC) | Poly-Vinyl Chloride (PVC) | ISO 10993 UL Style 2464 | 6 | Biological Compatibility Rip Cord | Copper Tinned | Black | -35 °C | 105 ░C | 0.813 mm | 0.032 in | 22 AWG | 0.219 " | 5.56 mm | |||||
 ALPHA WIRE | 30 AWG | 7 | 300 VDC | Multi-Conductor | Communication Control | 152.4 m | 500 ft | Poly-Vinyl Chloride (PVC) | Poly-Vinyl Chloride (PVC) | ISO 10993 UL Style 2464 | 6 | Biological Compatibility Rip Cord | Copper Tinned | Slate | -35 °C | 105 ░C | 0.813 mm | 0.032 in | 22 AWG | 0.219 " | 5.56 mm | |||||
ALPHA WIRE | 30 AWG | 7 | 300 VDC | Multi-Conductor | Communication Control | Poly-Vinyl Chloride (PVC) | Poly-Vinyl Chloride (PVC) | ISO 10993 UL Style 2464 | 6 | Biological Compatibility Rip Cord | Copper Tinned | Slate | -35 °C | 105 ░C | 0.813 mm | 0.032 in | 22 AWG | 0.219 " | 5.56 mm | 100 ft | 30.5 m | |||||
 ALPHA WIRE | 30 AWG | 7 | 300 VDC | Multi-Conductor | Poly-Vinyl Chloride (PVC) | Poly-Vinyl Chloride (PVC) | 6 | Oil Resistant Rip Cord UV Resistant | Copper Tinned | Slate | -30 ░C | 80 °C | 0.813 mm | 0.032 in | 22 AWG | 0.219 " | 5.56 mm | 3500 ft | 1066.8 m | Enter Number of Feet in Order Quantity |
