895-012 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 12POS 0.100
...
| Part | Termination Rows | Material - Insulation | Number of Positions | Contact Type | Mounting Type | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Rows | Color | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Number of Positions/Bay/Row | Card Type | Termination | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Read Out | Pitch | Pitch | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 12 | Cantilever | Through Hole | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 1 | Black | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 12 | Non Specified - Single Edge | Wire Wrap | Gold | 0.25 Ám | 10 Áin | Single | 0.1 " | 2.54 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 12 | Cantilever | Through Hole | Black | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Non Specified - Dual Edge | Solder | Gold | 0.25 Ám | 10 Áin | Dual | 0.1 " | 2.54 mm | 2 | 2 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 12 | Cantilever | Through Hole | Black | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Non Specified - Dual Edge | Solder | Gold | 0.25 Ám | 10 Áin | Dual | 0.1 " | 2.54 mm | 2 | 2 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 12 | Cantilever | Through Hole | M3 Threaded Insert Top Mount Opening | Black | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Non Specified - Dual Edge | Wire Wrap | Gold | 0.25 Ám | 10 Áin | Dual | 0.1 " | 2.54 mm | 2 | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 12 | Cantilever | Through Hole | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Black | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Non Specified - Dual Edge | Solder | Gold | 0.25 Ám | 10 Áin | Dual | 0.1 " | 2.54 mm | 2 | 2 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 12 | Cantilever | Board Edge Straddle Mount | 0.156 " | 3.96 mm | Black | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Non Specified - Dual Edge | Solder | Gold | 0.25 Ám | 10 Áin | Dual | 0.1 " | 2.54 mm | 2 | 2 | Card Extender | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 12 | Cantilever | Right Angle Through Hole | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Black | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Non Specified - Dual Edge | Solder | Gold | 0.25 Ám | 10 Áin | Dual | 0.1 " | 2.54 mm | 2 | 2 | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 12 | Cantilever | Through Hole | M3 Threaded Insert Top Mount Opening | 1 | Black | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 12 | Non Specified - Single Edge | Solder | Gold | 0.25 Ám | 10 Áin | Single | 0.1 " | 2.54 mm | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 12 | Cantilever | Through Hole | Flush Mount M3 Threaded Insert Top Opening | 1 | Black | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 12 | Non Specified - Single Edge | Wire Wrap | Gold | 0.25 Ám | 10 Áin | Single | 0.1 " | 2.54 mm | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 12 | Cantilever | Right Angle Through Hole | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Black | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Non Specified - Dual Edge | Solder | Gold | 0.25 Ám | 10 Áin | Dual | 0.1 " | 2.54 mm | 2 | 2 |
