FS450R12 Series

Manufacturer: INFINEON

Catalog

THE FS450R12KE3 IS A SIXPACK IGBT3 - E3 MODULE IN A ECONOPACK™ + B HOUSING FOR INDUSTRIAL APPLICATIONS UP TO 1200 V AND 450 A.

Part	Current - Collector (Ic) (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Input Capacitance (Cies) @ Vce	Vce(on) (Max) @ Vge, Ic	Power - Max [Max]	Configuration	Mounting Type	Voltage - Collector Emitter Breakdown (Max) [Max]	Supplier Device Package	IGBT Type	Input	Package / Case	Current - Collector Cutoff (Max) [Max]
INFINEON FS450R12KE3BOSA1	600 A	-40 C	125 °C	32 nF	2.15 V	2100 W	Three Phase Inverter	Chassis Mount	1200 V	Module	Trench Field Stop	Standard	Module	5 mA
INFINEON FS450R12OE4B81BPSA1	450 A	-40 °C	150 °C	27.9 nF	2.1 V	20 mW	Three Phase Inverter	Chassis Mount	1200 V	AG-ECONOPP	Trench Field Stop	Standard	Module	3 mA
INFINEON FS450R12OE4PBOSA1	900 A	-40 C	150 °C	1.55 nF	2.1 V	20 mW	Full Bridge	Chassis Mount	1200 V	Module	Trench Field Stop	Standard	Module	3 mA
INFINEON FS450R12KE4BOSA1	675 A	-40 C	150 °C	28 nF	2.1 V	2250 W	Full Bridge	Chassis Mount	1200 V	Module	Trench Field Stop	Standard	Module	3 mA
