5012C Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CBL 2COND 24AWG RED 1000=1000'
| Part | Usage | Cable Type | Ratings | Features | Operating Temperature [Min] | Operating Temperature [Max] | Jacket (Insulation) Diameter | Jacket (Insulation) Diameter | Number of Conductors | Wire Gauge | Conductor Insulation | Conductor Material | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Voltage | Jacket Color | Jacket (Insulation) Material | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Communication Control | Multi-Conductor | ISO 10993 UL Style 2464 | Biological Compatibility Rip Cord | -35 °C | 105 ░C | 0.156 in | 3.96 mm | 2 | 24 AWG | Poly-Vinyl Chloride (PVC) | Copper Tinned | 30 AWG | 7 | 0.813 mm | 0.032 in | 300 VDC | Red | Poly-Vinyl Chloride (PVC) | ||
 ALPHA WIRE | Communication Control | Multi-Conductor | ISO 10993 UL Style 2464 | Biological Compatibility Rip Cord | -35 °C | 105 ░C | 0.156 in | 3.96 mm | 2 | 24 AWG | Poly-Vinyl Chloride (PVC) | Copper Tinned | 30 AWG | 7 | 0.813 mm | 0.032 in | 300 VDC | Slate | Poly-Vinyl Chloride (PVC) | ||
ALPHA WIRE | Communication Control | Multi-Conductor | ISO 10993 UL Style 2464 | Biological Compatibility Rip Cord | -35 °C | 105 ░C | 0.156 in | 3.96 mm | 2 | 24 AWG | Poly-Vinyl Chloride (PVC) | Copper Tinned | 30 AWG | 7 | 0.813 mm | 0.032 in | 300 VDC | Slate | Poly-Vinyl Chloride (PVC) | 152.4 m | 500 ft |
ALPHA WIRE | Communication Control | Multi-Conductor | ISO 10993 UL Style 2464 | Biological Compatibility Rip Cord | -35 °C | 105 ░C | 0.156 in | 3.96 mm | 2 | 24 AWG | Poly-Vinyl Chloride (PVC) | Copper Tinned | 30 AWG | 7 | 0.813 mm | 0.032 in | 300 VDC | Blue | Poly-Vinyl Chloride (PVC) |
