LC4HW Series
Manufacturer: Panasonic Industrial Automation Sales
Beta
⌘K
COUNTER LCD 6 CHAR 12-24V PNL MT
| Part | Ingress Protection | Reset | Operating Temperature [Max] [custom] | Operating Temperature [Min] [custom] | Display Type | Operating Mode | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] | Input Type | Count Rate | Voltage - Supply [Max] | Voltage - Supply [Min] | Number of Characters Per Row | Number of Characters Per Row | Termination Style | Type | Output Type | Voltage - Supply |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Industrial Automation Sales | IP66 | External Front Panel | 55 °C | -10 °C | LCD - Dual Color Characters Backlight | Command Down Individual Quadrature Up | 45 mm | 45 mm | No Voltage | 5 kHz 30 Hz | 24 V | 12 V | 6 | 6 | Screw Terminal | Preset | ||
Panasonic Industrial Automation Sales | IP66 | External Front Panel | 55 °C | -10 °C | LCD - Dual Color Characters Backlight | Command Down Individual Quadrature Up | 45 mm | 45 mm | No Voltage | 5 kHz 30 Hz | 24 V | 12 V | 6 | 6 | Plug In 11 Pin (Octal) | Batch Tachometer Timer Totalizer | Relay (2) | |
Panasonic Industrial Automation Sales | IP66 | External Front Panel | 55 °C | -10 °C | LCD - Dual Color Characters Backlight | Command Down Individual Quadrature Up | 45 mm | 45 mm | No Voltage | 5 kHz 30 Hz | 6 | 6 | Plug In 11 Pin (Octal) | Batch Tachometer Timer Totalizer | Relay (2) | 24 VAC | ||
 Panasonic Industrial Automation Sales | IP66 | External Front Panel | 55 °C | -10 °C | LCD - Dual Color Characters Backlight | Command Down Individual Quadrature Up | 45 mm | 45 mm | No Voltage | 5 kHz 30 Hz | 24 V | 12 V | 6 | 6 | Plug In 11 Pin (Octal) | Batch Tachometer Timer Totalizer | Solid State (2) | |
Panasonic Industrial Automation Sales | IP66 | External Front Panel | 55 °C | -10 °C | LCD - Dual Color Characters Backlight | Command Down Individual Quadrature Up | 45 mm | 45 mm | No Voltage | 5 kHz 30 Hz | 240 VAC | 100 VAC | 6 | 6 | Plug In 11 Pin (Octal) | Batch Tachometer Timer Totalizer | Solid State (2) | |
Panasonic Industrial Automation Sales | IP66 | External Front Panel | 55 °C | -10 °C | LCD - Dual Color Characters Backlight | Command Down Individual Quadrature Up | 45 mm | 45 mm | No Voltage | 5 kHz 30 Hz | 240 VAC | 100 VAC | 6 | 6 | Screw Terminal | Batch Tachometer Timer Totalizer | Relay (2) |
