XT31 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RELAY GEN PURPOSE SPDT 16A 12V
| Part | Coil Resistance | Coil Type | Must Operate Voltage | Mounting Type | Relay Type | Switching Voltage [Max] | Contact Form | Termination Style | Contact Rating (Current) | Coil Insulation | Coil Voltage | Load - Max Switching | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Release Time | Coil Current | Must Release Voltage | Approval Agency | Operate Time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 360 Ohms | Non Latching | 8.4 VDC | Socketable | General Purpose | 400 VAC | SPDT (1 Form C) | Plug In | 16 A | Class F | 12 VDC | 6400 VA | Silver Nickel (AgNi) | 70 °C | -40 C | 6 ms | 16.7 mA | 1.2 VDC | cURus VDE | 9 ms |
 TE Connectivity AMP Connectors | 32500 Ohms | Non Latching | 184 VAC | Through Hole | General Purpose | 400 VAC | SPDT (1 Form C) | PC Pin | 16 A | Class F | 230 VAC | 6400 VA | Silver Nickel (AgNi) | 70 °C | -40 C | 6 ms | 16.7 mA | 34.5 VAC | cURus VDE | 8 ms |
 TE Connectivity AMP Connectors | 1440 Ohms | Non Latching | 16.8 VDC | Socketable | General Purpose | 400 VAC | SPDT (1 Form C) | Plug In | 16 A | Class F | 24 VDC | 6400 VA | Silver Nickel (AgNi) | 70 °C | -40 C | 6 ms | 16.7 mA | 2.4 VDC | cURus VDE | 9 ms |
 TE Connectivity AMP Connectors | 8.1 kOhms | Non Latching | 86.3 VAC | Socketable | General Purpose | 400 VAC | SPDT (1 Form C) | Plug In | 16 A | Class F | 115 VAC | 6400 VA | Silver Nickel (AgNi) | 70 °C | -40 C | 6 ms | 6.6 mA | 17.3 VAC | cURus VDE | 9 ms |
