APV Series

Catalog

ALUMINUM ORGANIC POLYMER CAPACITORS 6.3V 1000UF 2000HRS ESR=13MOHMS 20%

Part	Voltage - Rated	Capacitance	Type	Package / Case	Lifetime @ Temp.	Ripple Current @ Low Frequency	ESR (Equivalent Series Resistance)	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Height - Seated (Max) [Max]	Height - Seated (Max)	Surface Mount Land Size [x]	Surface Mount Land Size [y]	Surface Mount Land Size [x]	Surface Mount Land Size [y]	Tolerance	Mounting Type	Size / Dimension [diameter]	Size / Dimension [diameter]	Ripple Current @ High Frequency	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KYOCERA AVX APV0811102M006R	6.3 VDC	1000 µF	Polymer	Radial Can - SMD	2000 Hrs	225 mA	13 mOhms	-55 C	105 ░C	General Purpose	0.472 in	12 mm	8.3 mm	8.3 mm	0.327 in	0.327 in	20 %	Surface Mount	0.315 in	8 mm	4.5 A
KYOCERA AVX APV0811331M025R	25 VDC	330 µF	Polymer	Radial Can - SMD	2000 Hrs	145 mA	19 mOhm	-55 C	105 ░C	General Purpose	0.472 in	12 mm	8.3 mm	8.3 mm	0.327 in	0.327 in	20 %	Surface Mount	0.315 in	8 mm	2.9 A
KYOCERA AVX APV0811561M010R	10 V	560 µF	Polymer	Radial Can - SMD	2000 Hrs	185 mA		-55 C	105 ░C	General Purpose	0.472 in	12 mm	8.3 mm	8.3 mm	0.327 in	0.327 in	20 %	Surface Mount	0.315 in	8 mm	3.7 A
KYOCERA AVX APV0606101M025R	25 VDC	100 µF	Polymer	Radial Can - SMD	2000 Hrs	125 mA	27 mOhms	-55 C	105 ░C	General Purpose			6.6 mm	6.6 mm	0.26 in	0.26 in	20 %	Surface Mount	0.248 "	6.3 mm	2.5 A	6.5 mm	0.256 in
KYOCERA AVX APV0606680M010R	10 V	68 µF	Polymer	Radial Can - SMD	2000 Hrs	140 mA	45 mOhm	-55 C	105 ░C	General Purpose			6.6 mm	6.6 mm	0.26 in	0.26 in	20 %	Surface Mount	0.248 "	6.3 mm	2.8 A	6.5 mm	0.256 in
KYOCERA AVX APV1012102M016R	16 V	1000 µF	Polymer	Radial Can - SMD	2000 Hrs	215 mA		-55 C	105 ░C	General Purpose			10.3 mm	10.3 mm	0.406 "	0.406 in	20 %	Surface Mount	0.394 in	10 mm	4.3 A			0.512 "	13 mm
KYOCERA AVX APV0809271M016R	16 V	270 µF	Polymer	Radial Can - SMD	2000 Hrs	145 mA	22 mOhms	-55 C	105 ░C	General Purpose	0.394 in		8.3 mm	8.3 mm	0.327 in	0.327 in	20 %	Surface Mount	0.315 in	8 mm	2.9 A		10 mm
KYOCERA AVX APV0606561M002R	2.5 V	560 µF	Polymer	Radial Can - SMD	2000 Hrs	200 mA		-55 C	105 ░C	General Purpose			6.6 mm	6.6 mm	0.26 in	0.26 in	20 %	Surface Mount	0.248 "	6.3 mm	4 A	6.5 mm	0.256 in
