PH1200A281 Series
Isolated DC/DC Converters - Through Hole 1200W 24V 50A
Manufacturer: TDK Corporation
Catalog
Isolated DC/DC Converters - Through Hole 1200W 24V 50A
Beta
⌘K
Isolated DC/DC Converters - Through Hole 1200W 24V 50A
Isolated DC/DC Converters - Through Hole 1200W 24V 50A
Isolated DC/DC Converters - Through Hole 1200W 24V 50A
| Part | Voltage - Isolation | Operating Temperature [Min] | Operating Temperature [Max] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Voltage - Output 1 | Power (Watts) | Control Features | Approval Agency | Supplier Device Package | Package / Case | Features | Voltage - Input (Min) [Min] | Efficiency | Number of Outputs | Standard Number | Type | Voltage - Input (Max) [Max] | Mounting Type | Current - Output (Max) [Max] | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TDK Corporation | 3000 V | -40 °C | 100 °C | 2.4 in | 4.6 " | 12.7 mm | 0.5 in | 61 mm | 116.8 mm | 24 V | 1200 W | Active Low Enable | CE UKCA | Full Brick | Full Brick | Adjustable Output Baseplate Remote On/Off Remote Sense | 200 V | 94 % | 1 | 62368-1 | Isolated Module | 425 V | Through Hole | 50 A | ITE (Commercial) |
