AQY280 Series

Catalog

MOSFET RELAY, SPST-NO, 0.13A, 350V, SMD ROHS COMPLIANT: YES

Part	Voltage - Load [Max]	Operating Temperature [Max]	Operating Temperature [Min]	On-State Resistance (Max) [Max]	Package / Case	Package / Case	Package / Case	Supplier Device Package	Output Type	Termination Style	Approval Agency	Mounting Type	Load Current	Voltage - Input
Panasonic Electronic Components AQY280EHA	350 V	85 °C	-40 C	25 Ohms	0.3 in	4-SMD	7.62 mm	4-SMD	AC DC	Gull Wing	BSI cURus	Surface Mount	130 mA	1.14 VDC
Panasonic Electronic Components AQY280EHAX	350 V	85 °C	-40 C	25 Ohms	0.3 in	4-SMD	7.62 mm	4-SMD	AC DC	Gull Wing	BSI cURus	Surface Mount	130 mA	1.14 VDC
Panasonic Electronic Components AQY280EHAZ	350 V	85 °C	-40 C	25 Ohms	0.3 in	4-SMD	7.62 mm	4-SMD	AC DC	Gull Wing	BSI cURus	Surface Mount	130 mA	1.14 VDC
Panasonic Electronic Components AQY280SX	350 V	85 °C	-40 C	25 Ohms		4-SOP (0.173" 4.40mm)		4-SOP	AC DC	Gull Wing	BSI cURus	Surface Mount	120 mA	1.14 VDC
Panasonic Electronic Components AQY280SZ	350 V	85 °C	-40 C	25 Ohms		4-SOP (0.173" 4.40mm)		4-SOP	AC DC	Gull Wing	BSI cURus	Surface Mount	120 mA	1.14 VDC
Panasonic Electronic Components AQY280S	350 V	85 °C	-40 C	25 Ohms		4-SOP (0.173" 4.40mm)		4-SOP	AC DC	Gull Wing	BSI cURus	Surface Mount	120 mA	1.14 VDC
