AST135 Series
Manufacturer: METZ CONNECT USA Inc.
Beta
⌘K
TERM BLOCK 9POS 45DEG 5MM PCB
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material - Plating | Clamp Material - Plating | Positions Per Level | Mounting Type | Current | Color | Pitch | Pitch | Features | Mating Orientation | Mating Orientation | Wire Termination | Number of Levels | Voltage | Wire Gauge [Max] | Wire Gauge [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 METZ CONNECT USA Inc. | -40 C | 105 ░C | Copper Alloy - Tin Plated | Steel | 9 | Through Hole | 13 A | Gray | 0.197 in | 5 mm | Lever Actuated | 135 ° | 45 ° | Screwless - Spring Cage Tension Clamp | 1 | 300 VDC | 28 AWG | 14 AWG |
 METZ CONNECT USA Inc. | -40 C | 105 ░C | Copper Alloy - Tin Plated | Steel | 6 | Through Hole | 13 A | Gray | 0.197 in | 5 mm | Lever Actuated | 135 ° | 45 ° | Screwless - Spring Cage Tension Clamp | 1 | 300 VDC | 28 AWG | 14 AWG |
 METZ CONNECT USA Inc. | -40 C | 105 ░C | Copper Alloy - Tin Plated | Steel | 4 | Through Hole | 13 A | Gray | 0.197 in | 5 mm | Lever Actuated | 135 ° | 45 ° | Screwless - Spring Cage Tension Clamp | 1 | 300 VDC | 28 AWG | 14 AWG |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Copper Alloy - Tin Plated | Steel | 3 | Through Hole | 13 A | Gray | 0.197 in | 5 mm | Lever Actuated | 135 ° | 45 ° | Screwless - Spring Cage Tension Clamp | 1 | 300 VDC | 28 AWG | 14 AWG |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Copper Alloy - Tin Plated | Steel | 13 | Through Hole | 13 A | Gray | 0.197 in | 5 mm | Lever Actuated | 135 ° | 45 ° | Screwless - Spring Cage Tension Clamp | 1 | 300 VDC | 28 AWG | 14 AWG |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Copper Alloy - Tin Plated | Steel | 11 | Through Hole | 13 A | Gray | 0.197 in | 5 mm | Lever Actuated | 135 ° | 45 ° | Screwless - Spring Cage Tension Clamp | 1 | 300 VDC | 28 AWG | 14 AWG |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Copper Alloy - Tin Plated | Steel | 5 | Through Hole | 13 A | Gray | 0.197 in | 5 mm | Lever Actuated | 135 ° | 45 ° | Screwless - Spring Cage Tension Clamp | 1 | 300 VDC | 28 AWG | 14 AWG |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Copper Alloy - Tin Plated | Steel | 16 | Through Hole | 13 A | Gray | 0.197 in | 5 mm | Lever Actuated | 135 ° | 45 ° | Screwless - Spring Cage Tension Clamp | 1 | 300 VDC | 28 AWG | 14 AWG |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Copper Alloy - Tin Plated | Steel | 15 | Through Hole | 13 A | Gray | 0.197 in | 5 mm | Lever Actuated | 135 ° | 45 ° | Screwless - Spring Cage Tension Clamp | 1 | 300 VDC | 28 AWG | 14 AWG |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Copper Alloy - Tin Plated | Steel | 2 | Through Hole | 13 A | Gray | 0.197 in | 5 mm | Lever Actuated | 135 ° | 45 ° | Screwless - Spring Cage Tension Clamp | 1 | 300 VDC | 28 AWG | 14 AWG |
