SIT9367 Series

Manufacturer: SiTime

Catalog

MEMS OSC XO 644.53125MHZ LVDS

Part	Current - Supply (Disable) (Max) [Max]	Function	Supplier Device Package	Voltage - Supply	Output	Base Resonator	Current - Supply (Max) [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Type	Frequency	Package / Case	Mounting Type	Frequency Stability	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [y]	Supplier Device Package [x]	Supplier Device Package [y]
SiTime SIT9367AE-2E1-33E644.531250	63 mA	Enable/Disable	6-PQFV (7x5)	3.3 V	LVDS	MEMS	85 mA	5 mm	7 mm	0.197 "	0.276 "	0.035 in	0.9 mm	XO (Standard)	644.53125 MHz	6-SMD No Lead Exposed Pad	Surface Mount	20 ppm	-40 C	105 ░C
SiTime SIT9367AI-2E3-25E266.000000	63 mA	Enable/Disable	6-PQFV (7x5)	2.5 V	LVDS	MEMS	85 mA	5 mm	7 mm	0.197 "	0.276 "	0.035 in	0.9 mm	XO (Standard)	266 MHz	6-SMD No Lead Exposed Pad	Surface Mount	50 ppm	-40 C	85 °C
SiTime SIT9367AC-2CF-33N408.000000X			6-PQFV (5x3.2)	3.3 V	LVDS	MEMS	85 mA		5 mm	0.126 in	0.197 in	0.035 in	0.9 mm	XO (Standard)	408 MHz	6-SMD No Lead Exposed Pad	Surface Mount	10 ppm	-20 ░C	70 °C	3.2 mm
SiTime SIT9367AI-2B1-33E400.000000	63 mA	Enable/Disable	6-PQFD	3.3 V	LVDS	MEMS	85 mA	2.5 mm	3.2 mm	0.098 in	0.126 "	0.035 in	0.9 mm	XO (Standard)	400 MHz	6-SMD No Lead	Surface Mount	20 ppm	-40 C	85 °C		3.2	2.5
SiTime SIT9367AI-2B1-25E249.375000	63 mA	Enable/Disable	6-PQFD	2.5 V	LVDS	MEMS	85 mA	2.5 mm	3.2 mm	0.098 in	0.126 "	0.035 in	0.9 mm	XO (Standard)	249.375 MHz	6-SMD No Lead	Surface Mount	20 ppm	-40 C	85 °C		3.2	2.5
SiTime SIT9367AI-2B1-25E248.675000	63 mA	Enable/Disable	6-PQFD	2.5 V	LVDS	MEMS	85 mA	2.5 mm	3.2 mm	0.098 in	0.126 "	0.035 in	0.9 mm	XO (Standard)	248.675 MHz	6-SMD No Lead	Surface Mount	20 ppm	-40 C	85 °C		3.2	2.5
SiTime SIT9367AC-2CF-33N639.000000X			6-PQFV (5x3.2)	3.3 V	LVDS	MEMS	85 mA		5 mm	0.126 in	0.197 in	0.035 in	0.9 mm	XO (Standard)	639 MHz	6-SMD No Lead Exposed Pad	Surface Mount	10 ppm	-20 ░C	70 °C	3.2 mm
SiTime SIT9367AI-1B1-33E640.000000		Enable/Disable	6-PQFD	3.3 V	LVPECL	MEMS	94 mA	2.5 mm	3.2 mm	0.098 in	0.126 "	0.035 in	0.9 mm	XO (Standard)	640 MHz	6-SMD No Lead	Surface Mount	20 ppm	-40 C	85 °C		3.2	2.5
SiTime SIT9367AI-2B1-25E250.075000	63 mA	Enable/Disable	6-PQFD	2.5 V	LVDS	MEMS	85 mA	2.5 mm	3.2 mm	0.098 in	0.126 "	0.035 in	0.9 mm	XO (Standard)	250.075 MHz	6-SMD No Lead	Surface Mount	20 ppm	-40 C	85 °C		3.2	2.5
