FLEXPAC Series
FFC & FPC Connectors FPH-2202G=FLXPAC HDR P 22 RA LF
Manufacturer: TE Connectivity AMP Connectors
Catalog
FFC & FPC Connectors FPH-2202G=FLXPAC HDR P 22 RA LF
FFC & FPC Connectors FPH-2202G=FLXPAC HDR P 22 RA LF
FFC & FPC Connectors FPH-2202G=FLXPAC HDR P 22 RA LF
FFC & FPC Connectors FPH-2202G=FLXPAC HDR P 22 RA LF
| Part | Contact Length - Mating | Contact Length - Mating | Contact Finish - Post | Number of Positions | Contact Material | Fastening Type | Number of Positions Loaded | Shrouding | Insulation Height | Insulation Height [z] | Style | Connector Type | Termination | Contact Shape | Contact Finish - Mating | Pitch - Mating | Pitch - Mating | Voltage Rating | Mounting Type | Contact Type | Insulation Color | Operating Temperature [Max] | Operating Temperature [Min] | Current Rating (Amps) | Number of Rows | Contact Length - Post | Contact Length - Post | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Material Flammability Rating | Insulation Material | Number of Rows [custom] | Insulation Height | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Features | Insulation Height [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors | 5.97 mm | 0.235 in | Tin | 10 | Phosphor Bronze | Latch Holder | All | Shrouded - 4 Wall | 9.65 mm | 0.38 in | Board to Cable/Wire | Header | Solder | Square | Gold | 0.1 " | 2.54 mm | 300 VAC | Through Hole | Male Pin | Blue | 105 ░C | -65 ░C | 2 A | 1 | 0.1 in | 2.54 mm | 0.76 Ám | 30 Áin | UL94 V-0 | Nylon Polyamide (PA) | ||||||
TE Connectivity AMP Connectors | 5.97 mm | 0.235 in | Tin | 52 | Phosphor Bronze | Latch Holder | All | Shrouded - 4 Wall | 8.94 mm | Board to Cable/Wire | Header | Solder | Square | Gold | 0.1 " | 2.54 mm | 300 VAC | Right Angle Through Hole | Male Pin | Blue | 105 ░C | -65 ░C | 2 A | 0.1 in | 2.54 mm | 0.76 Ám | 30 Áin | UL94 V-0 | Nylon Polyamide (PA) | 2 | 0.352 in | 0.1 in | 2.54 mm | Keying Slot | |||
TE Connectivity AMP Connectors | 5.97 mm | 0.235 in | Tin | 24 | Phosphor Bronze | Latch Holder | All | Shrouded - 4 Wall | 9.65 mm | 0.38 in | Board to Cable/Wire | Header | Solder | Square | 0.1 " | 2.54 mm | 300 VAC | Through Hole | Male Pin | Blue | 105 ░C | -65 ░C | 2 A | 0.1 in | 2.54 mm | 2.54 çm | 100 çin | UL94 V-0 | Nylon Polyamide (PA) | 2 | 0.1 in | 2.54 mm | Keying Slot | ||||
TE Connectivity AMP Connectors | 5.97 mm | 0.235 in | Tin | 60 | Phosphor Bronze | Latch Holder | All | Shrouded - 4 Wall | 9.65 mm | 0.38 in | Board to Cable/Wire | Header | Solder | Square | Gold | 0.1 " | 2.54 mm | 300 VAC | Through Hole | Male Pin | Blue | 105 ░C | -65 ░C | 2 A | 0.1 in | 2.54 mm | 0.76 Ám | 30 Áin | UL94 V-0 | Nylon Polyamide (PA) | 2 | 0.1 in | 2.54 mm | Keying Slot | |||
TE Connectivity AMP Connectors | 5.97 mm | 0.235 in | Tin | 22 | Phosphor Bronze | Latch Lock | All | Shrouded - 4 Wall | 0.429 in | Board to Cable/Wire | Header | Solder | Square | Gold | 0.1 " | 2.54 mm | 300 VAC | Right Angle Through Hole | Male Pin | Blue | 105 ░C | -65 ░C | 2 A | 0.1 in | 2.54 mm | 0.76 Ám | 30 Áin | UL94 V-0 | Nylon Polyamide (PA) | 2 | 0.1 in | 2.54 mm | Keying Slot | 10.9 mm |
