NEOHM CPF Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

Catalog

RES SMD 2.67KOHM 0.1% 1/10W 0805

...

Part	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Tolerance	Resistance	Composition	Package / Case	Supplier Device Package	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Number of Terminations [custom]	Temperature Coefficient	Operating Temperature [Max]	Operating Temperature [Min]	Power (Watts)	Power (Watts)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Package / Case	Height - Seated (Max)	Features
TE Connectivity AMP Connectors CPF0805B2K67E1	0.026 in	0.65 mm	0.1 %	2.67 kOhms	Thin Film	0805	0805	2 mm	1.25 mm	0.049 "	0.079 in	2	25 ppm/°C	155 C	-55 C	0.1 W	0.1 W
TE Connectivity AMP Connectors CPF0402B274RE1			0.1 %	274 Ohms	Thin Film	0402 (1005 Metric)	0402	1 mm	0.5 mm	0.02 in	0.039 "	2	25 ppm/°C	155 C	-55 C	0.063 W	0.0625 W	0.35 mm	0.014 "
TE Connectivity AMP Connectors CPF0201B7K32E1	0.011 "		0.1 %	7320 Ohms	Thin Film	0201	0201	0.58 mm	0.29 mm	0.011 in	0.023 in	2	25 ppm/°C	155 C	-55 C	30 mW	0.03125 W			0603 Metric	0.28 mm
TE Connectivity AMP Connectors CPF1206B510KE1	0.026 in	0.65 mm	0.1 %	510 kOhms	Thin Film	1206 (3216 Metric)	1206					2	25 ppm/°C	155 C	-55 C	0.125 W	0.125 W
TE Connectivity AMP Connectors CPF0201B1K21E1	0.011 "		0.1 %	1.21 kOhms	Thin Film	0201	0201	0.58 mm	0.29 mm	0.011 in	0.023 in	2	25 ppm/°C	155 C	-55 C	30 mW	0.03125 W			0603 Metric	0.28 mm
TE Connectivity AMP Connectors CPF0402B2K2E			0.1 %	2200 Ohms	Thin Film	0402 (1005 Metric)	0402	1 mm	0.5 mm	0.02 in	0.039 "	2	25 ppm/°C	155 C	-55 C	0.063 W	0.0625 W	0.35 mm	0.014 "
TE Connectivity AMP Connectors CPF0603B649RE1	0.022 in	0.55 mm	0.1 %	649 Ohms	Thin Film	0603						2	25 ppm/°C	155 C	-55 C	0.063 W	0.0625 W			1608 Metric
TE Connectivity AMP Connectors CPF0603F15R8C1	0.022 in	0.55 mm	1 %	15.8 Ohms	Thin Film	0603						2	50 ppm/░C	155 C	-55 C	0.063 W	0.0625 W			1608 Metric
TE Connectivity AMP Connectors CPF0805B365KE	0.026 in	0.65 mm	0.1 %	365 kOhms	Thin Film	0805	0805	2 mm	1.25 mm	0.049 "	0.079 in	2	25 ppm/°C	155 C	-55 C	0.1 W	0.1 W
TE Connectivity AMP Connectors CPF-A-0805B5K1E1	0.026 in	0.65 mm	0.1 %	5.1 kOhms	Thin Film	0805	0805	2 mm	1.25 mm	0.049 "	0.079 in	2	25 ppm/°C	155 C	-55 C	0.1 W	0.1 W					Anti-Sulfur Automotive AEC-Q200 Moisture Resistant
