GoldMax 300 Comm X7R HV Series

Manufacturer: KEMET

Catalog

MULTILAYER CERAMIC CAPACITORS MLCC - LEADED 500V 0.01UF X7R 20% LS=5.08MM

Part	Temperature Coefficient	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Lead Style	Applications	Lead Spacing	Lead Spacing	Height - Seated (Max) [Max]	Height - Seated (Max)	Features	Package / Case	Capacitance	Tolerance	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Voltage - Rated	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Voltage - Rated
KEMET C323C103MCR5TA7301	X7R	-55 C	125 °C	Through Hole	Formed Leads	Bypass Decoupling	0.2 in	5.08 mm	0.3 in	7.62 mm	High Voltage	Radial	10000 pF	20 %	3.18 mm	0.2 in	5.08 mm	0.125 "	500 V
KEMET C330C224MCR5TA7303	X7R	-55 C	125 °C	Through Hole	Straight	Bypass Decoupling	0.2 in	5.08 mm			High Voltage	Radial	0.22 µF	20 %	5.08 mm	0.3 "	7.62 mm	0.2 in	500 V	10.66 mm	0.42 in
KEMET C320C822KCR5HA	X7R	-55 C	125 °C	Through Hole	Straight	Bypass Decoupling	0.1 in	2.54 mm			High Voltage	Radial		10 %	3.81 mm	0.2 in	5.08 mm	0.15 "	500 V	7.36 mm	0.29 in
KEMET C322C102KCR5TA7301	X7R	-55 C	125 °C	Through Hole	Straight	Bypass Decoupling	0.2 in	5.08 mm	0.26 in		High Voltage	Radial	0.001 µF	10 %	3.81 mm	0.2 in	5.08 mm	0.15 "	500 V			6.6 mm
KEMET C320C561KCR5TA	X7R	-55 C	125 °C	Through Hole	Straight	Bypass Decoupling	0.1 in	2.54 mm			High Voltage	Radial	560 pF	10 %	3.81 mm	0.2 in	5.08 mm	0.15 "	500 V	7.36 mm	0.29 in
KEMET C322C332KDR5TA7301	X7R	-55 C	125 °C	Through Hole	Straight	Bypass Decoupling	0.2 in	5.08 mm	0.26 in		High Voltage	Radial	0.0033 µF	10 %	3.81 mm	0.2 in	5.08 mm	0.15 "	1000 V			6.6 mm	1 kV
KEMET C320C682KCR5TA	X7R	-55 C	125 °C	Through Hole	Straight	Bypass Decoupling	0.1 in	2.54 mm			High Voltage	Radial	6800 pF	10 %	3.81 mm	0.2 in	5.08 mm	0.15 "	500 V	7.36 mm	0.29 in
KEMET C317C221MDR5HA7301	X7R	-55 C	125 °C	Through Hole	Formed Leads	Bypass Decoupling	0.2 in	5.08 mm			High Voltage	Radial	220 pF	20 %	3.14 mm	0.15 "	3.81 mm	0.124 in	1000 V	5.08 mm	0.2 in		1 kV
KEMET C322C102KFR5TA7301	X7R	-55 C	125 °C	Through Hole	Straight	Bypass Decoupling	0.2 in	5.08 mm	0.26 in		High Voltage	Radial	0.001 µF	10 %	3.81 mm	0.2 in	5.08 mm	0.15 "	1500 V			6.6 mm	1.5 kV
KEMET C320C104KCR5TA7303	X7R	-55 C	125 °C	Through Hole	Straight	General Purpose	0.1 in	2.54 mm			High Voltage	Radial	100000 pF	10 %	3.81 mm	0.2 in	5.08 mm	0.15 "	500 V	7.36 mm	0.29 in
