LFH Series

250V CLASS H BLOCK 100A 1 POLE

Catalog

250V CLASS H BLOCK 100A 1 POLE

Part	Mounting Type	Voltage	For Use With/Related Products	Number of Circuits	Termination Style	Fuse Type	Fuseholder Type	Current Rating (Amps)	Fuse Size [custom]	Fuse Size [diameter]	Fuse Size [custom]	Fuse Size [diameter]	Fuse Size [x]	Fuse Size [x]
LITTELFUSE LFH600602CID	DIN Rail	600 V	Class H(K) Class R Fuses	2	Box Lug	Cartridge	Block	60 A
LITTELFUSE LFJ600302CID	DIN Rail	600 V	Class J Fuses	2	Box Lug	Cartridge	Block	30 A	57.15 mm	0.813 in	2.25 in	20.65 mm
LITTELFUSE LFJ600302PID	DIN Rail	600 V	Class J Fuses	2	Pressure Plate Screw Terminal	Cartridge	Block	30 A	57.15 mm	0.813 in	2.25 in	20.65 mm
LITTELFUSE LFH251001CID	DIN Rail	250 VDC	Class H(K) Class R Fuses	1	Box Lug	Cartridge	Block	100 A
LITTELFUSE LFH602003C	DIN Rail	600 V	Class H(K) Class R Fuses	3	Box Lug	Cartridge	Block	200 A
LITTELFUSE LFJ600601CID	DIN Rail	600 V	Class J Fuses	1	Box Lug	Cartridge	Block	60 A		1.063 in		27 mm	2.374 in	60.3 mm
LITTELFUSE LFH606003C	DIN Rail	600 V	Class H(K) Class R Fuses	3	Box Lug	Cartridge	Block	600 A
LITTELFUSE LFH250601C	DIN Rail	250 VDC	Class H(K) Class R Fuses	1	Box Lug	Cartridge	Holder	60 A
LITTELFUSE LFH250601CID	DIN Rail	250 VDC	Class H(K) Class R Fuses	1	Box Lug	Cartridge	Block	60 A

Catalog

250V CLASS H BLOCK 100A 1 POLE

Description

The new Littelfuse Class H blocks offer many advantages over previous generations that are noted in the features and benefits section. Class H and Class R fuse blocks are dimensionally the same, but Class R blocks incorporate a rejection feature, which only allows Class R fuses to be inserted. Note: For reinforcing clips on Class H blocks rated 30-60 amp, add "R" suffix to connector type
