810 Series

Catalog

SCOTCH MAGIC TRANSPARENT TAPE 81

Part	Adhesive	Length	Length	Length	Color	Width	Width	Width	Backing, Carrier	Usage	Tape Type	Termination	Contact Finish - Mating	Insulation Color	Pitch - Mating	Pitch - Mating	Contact Finish - Post	Contact Length - Mating	Contact Length - Mating	Features	Connector Type	Style	Insulation Material	Material Flammability Rating	Contact Shape	Insulation Height	Insulation Height	Mounting Type	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Type	Contact Material	Number of Positions Loaded	Fastening Type	Shrouding	Number of Positions	Number of Rows [custom]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Length - Post	Contact Length - Post
3M Electronic Specialty 810-6PK
3M Electronic Specialty 810H2 1/2"X1296"
3M Electronic Specialty 810 1/2"X36 YD	Acrylic	32.9 m	108 ft	36 yd	Clear	12.7 mm	0.5 "	0.5 in	Acetate	General Purpose	Household
3M Electronic Specialty 81060-660C07-RB												Solder	Gold	Black	1.27 mm	0.05 in	Tin	3.56 mm	0.14 in	Retention Clips	Header	Board to Cable/Wire	Liquid Crystal Polymer (LCP)	UL94 V-0	Square	10.29 mm	0.405 in	Surface Mount	0.1 in	2.54 mm	Male Pin	Copper Alloy	All	Latch Lock/Eject Hooks Long	Shrouded - 4 Wall	60	2	0.76 Ám	30 Áin	-55 C	105 ░C
3M Electronic Specialty 810-2P12-72
3M Electronic Specialty 810K6
3M Electronic Specialty 81026-500203												Solder	Gold	Black	1.27 mm	0.05 in	Tin-Lead	3.56 mm	0.14 in	Board Lock	Header	Board to Cable/Wire	Liquid Crystal Polymer (LCP)	UL94 V-0	Square	7.87 mm	0.31 in	Right Angle Through Hole	0.1 in	2.54 mm	Male Pin	Copper Alloy	All	Push-Pull	Shrouded - 4 Wall	26	2	0.76 Ám	30 Áin	-55 C	105 ░C	3.18 µm	125 µin	2.29 mm	0.09 in
3M Electronic Specialty 81040-560203												Solder	Gold	Black	1.27 mm	0.05 in	Tin-Lead	3.56 mm	0.14 in	Board Lock	Header	Board to Cable/Wire	Liquid Crystal Polymer (LCP)	UL94 V-0	Square	7.87 mm	0.31 in	Right Angle Through Hole	0.1 in	2.54 mm	Male Pin	Copper Alloy	All	Latch Lock/Eject Hooks Long	Shrouded - 4 Wall	40	2	0.76 Ám	30 Áin	-55 C	105 ░C			2.29 mm	0.09 in
3M Electronic Specialty 810-72-3PK
3M Electronic Specialty 81036-600203-RB												Solder	Gold	Black	1.27 mm	0.05 in	Tin	3.56 mm	0.14 in	Board Lock	Header	Board to Cable/Wire	Liquid Crystal Polymer (LCP)	UL94 V-0	Square	10.29 mm	0.405 in	Through Hole	0.1 in	2.54 mm	Male Pin	Copper Alloy	All	Push-Pull	Shrouded - 4 Wall	36	2	0.76 Ám	30 Áin	-55 C	105 ░C			2.34 mm	0.092 in
