R31740 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SHV F SQF
| Part | Dielectric Material | Body Finish | Body Material | Mating Cycles | Center Contact Plating | Operating Temperature [Min] | Operating Temperature [Max] | Housing Color | Connector Type | Mounting Type | Frequency - Max [Max] | Shield Termination | Mounting Feature | Connector Style | Number of Ports | Impedance | Contact Termination | Features | Center Contact Material | Fastening Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Polytetrafluoroethylene (PTFE) | Nickel | Brass | 500 | Gold | -65 ░C | 165 °C | Silver | Receptacle Male Pin | Panel Mount | 2 GHz | Solder | Flange | SHV | 1 | 50 Ohms | Solder Cup | Extended Insulation | Beryllium Copper Brass | Bayonet Lock |
