TRWB092 Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
CONN PCI CARDEDGE FML 184P 0.050
| Part | Material - Insulation | Card Type | Card Type | Read Out | Features | Card Thickness | Card Thickness | Gender | Mounting Type | Termination | Contact Finish Thickness | Contact Finish Thickness | Color | Pitch | Pitch | Contact Type | Contact Finish | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Contact Material | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sullins Connector Solutions | Polybutylene Terephthalate (PBT) | PCI 5V 64 Bit | 5 V 64 Bit | Dual | Board Lock | 1.57 mm | 0.062 in | Female | Through Hole | Solder | 5 µin | 0.127 µm | White | 0.05 in | 1.27 mm | Cantilever | Gold | -55 C | 85 °C | 184 | Brass | 2 |
Sullins Connector Solutions | Polybutylene Terephthalate (PBT) | PCI 5V 64 Bit | 5 V 64 Bit | Dual | Board Lock | 1.57 mm | 0.062 in | Female | Through Hole | Solder Staggered | 5 µin | 0.127 µm | White | 0.05 in | 1.27 mm | Cantilever | Gold | -55 C | 85 °C | 184 | Brass | 2 |
 Sullins Connector Solutions | Thermoplastic Glass Filled | PCI™ | Dual | 1.57 mm | 0.062 in | Female | Right Angle Through Hole | Solder | 5 µin | 0.127 µm | White | 0.05 in | 1.27 mm | Cantilever | Gold | -55 C | 85 °C | 184 | Copper Alloy | 2 | ||
Sullins Connector Solutions | Polybutylene Terephthalate (PBT) | PCI 3.3V 5V 32 Bit (Universal) | Dual | Board Lock | 1.57 mm | 0.062 in | Female | Through Hole | Solder Staggered | 5 µin | 0.127 µm | White | 0.05 in | 1.27 mm | Cantilever | Gold | -55 C | 85 °C | 184 | Brass | 2 | |
Sullins Connector Solutions | Polybutylene Terephthalate (PBT) | PCI 5V 64 Bit | 5 V 64 Bit | Dual | 1.57 mm | 0.062 in | Female | Right Angle Through Hole | Solder | 5 µin | 0.127 µm | White | 0.05 in | 1.27 mm | Cantilever | Gold | -55 C | 85 °C | 184 | Copper Alloy | 2 | |
Sullins Connector Solutions | Polybutylene Terephthalate (PBT) | Dual | 1.57 mm | 0.062 in | Female | Right Angle Through Hole | Solder | 5 µin | 0.127 µm | White | 0.05 in | 1.27 mm | Cantilever | Gold | -55 C | 85 °C | 184 | Copper Alloy | 2 | |||
 Sullins Connector Solutions | Thermoplastic Glass Filled | Dual | Board Lock | 1.57 mm | 0.062 in | Female | Through Hole | Solder | 5 µin | 0.127 µm | White | 0.05 in | 1.27 mm | Cantilever | Gold | -55 C | 85 °C | 184 | Copper Alloy | 2 | ||
 Sullins Connector Solutions | Polybutylene Terephthalate (PBT) | PCI 5V 64 Bit | 5 V 64 Bit | Dual | Board Guide | 1.57 mm | 0.062 in | Female | Through Hole | Solder Staggered | 5 µin | 0.127 µm | White | 0.05 in | 1.27 mm | Cantilever | Gold | -55 C | 85 °C | 184 | Brass | 2 |
