11-610 Series
Manufacturer: 3M Electronic Specialty
Beta
⌘K
22-18 AWG NON-INSULATED BRAZED SEAM MULTI-STUD RING TONGUE TER
| Part | Features | Terminal Type | Thickness | Thickness | Insulation | Mounting Type | Termination | Width - Outer Edges [x] | Width - Outer Edges [x] | Length - Overall [x] | Length - Overall [x] | Stud/Tab Size | Contact Finish | Wire Gauge [Max] | Wire Gauge [Min] | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 3M Electronic Specialty | Brazed Seam | Multi-Stud | 0.76 mm | 0.03 in | Non-Insulated | Free Hanging (In-Line) | Crimp | 7.11 mm | 0.28 in | 0.81 " | 20.57 mm | 6 Stud 8 Stud 10 Stud | Tin | 22 AWG | 17.5 AWG | Copper ETP |
