SoftPot Series

Catalog

INDUSTRIAL MOTION & POSITION SENSORS SOFTPOT LINEAR POTENTIOMETER (EXTRA-LONG) BY SPECTRA SYMBOL 750MM VARIANT MP - MALE PINS CONNECTOR +/-3% LINEARITY

Part	Resistance Tolerance	Package / Case	Linearity	Resistance	Mounting Type	Linear Range [Min] [x]	Linear Range [Min] [x]	Linear Range [Max] [x]	Linear Range [Max] [x]	For Measuring	Technology	Actuator Type	Termination Style	Output	Operating Temperature [Min]	Operating Temperature [Max]	Linear Range [Max]	Linear Range [Max]	Linear Range [Min]	Linear Range [Min]	Linear Range [Min]	Linear Range [Max]	Rotation Angle - Electrical, Mechanical [Min]	Rotation Angle - Electrical, Mechanical [Max]
Spectra Symbol SP-L-0750-203-3%-MP	20 %	Sensor Strip	3 %	20 kOhms	Custom	0 in	0 mm	29.53 in	750 mm	Linear Position	Resistive	Flexible Membrane - Linear	PC Pin	Resistive	-40 C	50 °C
Spectra Symbol SP-L-0100-103-3%-ST	20 %	Sensor Strip	3 %	10000 Ohms	Custom					Linear Position	Resistive	Flexible Membrane - Linear	Solder Tab	Resistive	-40 C	50 °C	100 mm	3.94 "	0 mm	0 "
Spectra Symbol SP-L-1000-203-1%-RLD	20 %	Sensor Strip	1 %	20 kOhms	Custom					Linear Position	Resistive	Flexible Membrane - Linear	Connector	Resistive	-40 C	50 °C		1000 mm		0 "	0 in	39.37 "
Spectra Symbol SP-L-0400-203-3%-RLD	20 %	Sensor Strip	3 %	20 kOhms	Custom					Linear Position	Resistive	Flexible Membrane - Linear	Connector	Resistive	-40 C	50 °C		400 mm	0 mm		0 in	15.75 in
Spectra Symbol SP-L-0012-103-1%-RLD	20 %	Sensor Strip	1 %	10000 Ohms	Custom					Linear Position	Resistive	Flexible Membrane - Linear	Connector	Resistive	-40 C	50 °C	12.5 mm	0.49 in	0 mm	0 "
Spectra Symbol SP-L-0400-203-1%-MP	20 %	Sensor Strip	1 %	20 kOhms	Custom					Linear Position	Resistive	Flexible Membrane - Linear	PC Pin	Resistive	-40 C	50 °C		400 mm	0 mm		0 in	15.75 in
Spectra Symbol SP-L-0500-203-3%-RLD	20 %	Sensor Strip	3 %	20 kOhms	Custom					Linear Position	Resistive	Flexible Membrane - Linear	Connector	Resistive	-40 C	50 °C	500 mm	19.69 in	0 mm	0 "
Spectra Symbol SP-L-0170-103-3%-MP	20 %	Sensor Strip	3 %	10000 Ohms	Custom	0 in	0 mm	6.69 in	170 mm	Linear Position	Resistive	Flexible Membrane - Linear	PC Pin	Resistive	-40 C	50 °C
Spectra Symbol SP-L-0300-103-3%-RLD	20 %	Sensor Strip	3 %	10000 Ohms	Custom		0 mm		11.81 in 300 mm	Linear Position	Resistive	Flexible Membrane - Linear	Connector	Resistive	-40 C	50 °C
Spectra Symbol SP-R-0046-353-103-5%-ST	20 %	Circle Sensor Strip	5 %	10000 Ohms	Custom					Rotary Position	Resistive	Flexible Membrane - Rotary	Solder Tab	Resistive	-40 C	50 °C							0 °	353 °
