SRP0415 Series
Manufacturer: Bourns Inc.
Beta
⌘K
POWER INDUCTORS - SMD IND,4.4X4.1X1.5MM,2.2UH+/-10%,4.2A,SHD,SMD
| Part | Current Rating (Amps) | Tolerance | Shielding | Frequency - Self Resonant | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Material - Core | DC Resistance (DCR) [Max] | Q @ Freq [custom] | Q @ Freq [custom] | Mounting Type | Package / Case | Inductance | Inductance Frequency - Test | Operating Temperature [Max] | Operating Temperature [Min] | Height - Seated (Max) [Max] | Height - Seated (Max) | Current - Saturation (Isat) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 4.2 A | 10 % | Shielded | 33 MHz | 4.1 mm | 0.173 in | 4.4 mm | 0.161 in | Metal | 48 mOhm | 42 | 7.96 MHz | Surface Mount | Nonstandard | 2.2 µH | 100 kHz | 125 °C | -40 C | 0.059 " | 1.5 mm | 6.5 A |
