M3CCK Series

Catalog

IDC CABLE - MKC40K/MC40G/MKC40K

Part	Length	Length	Connector Type	Pitch - Cable	Pitch - Cable	Number of Positions	Cable Termination	Contact Finish Thickness	Contact Finish Thickness	Features	Shielding	Contact Finish	Number of Rows [custom]	Pitch - Connector	Pitch - Connector	Length [x]	Length [x]	Color	Number of Positions [custom]
3M Electronic Specialty M3CCK-4036J	91.44 cm	3 ft	Socket to Socket	0.05 in	1.27 mm	40	IDC	30 Áin	0.76 Ám	Polarizing Key	Unshielded	Gold	2	0.1 in	2.54 mm
3M Electronic Specialty M3CCK-5018R			Socket to Socket	0.05 in	1.27 mm	50	IDC	30 Áin	0.76 Ám	Polarizing Key	Unshielded	Gold	2	0.1 in	2.54 mm	457.2 mm	1.5 ft	Multiple Ribbon
3M Electronic Specialty M3CCK-3440K	1.02 m	3.34 ft	Socket to Socket	0.05 in	1.27 mm		IDC	30 Áin	0.76 Ám	Polarizing Key	Unshielded	Gold	2	0.1 in	2.54 mm			Multiple Twisted Pair (Flat)	34
3M Electronic Specialty M3CCK-2018J			Socket to Socket	0.05 in	1.27 mm	20	IDC	30 Áin	0.76 Ám	Polarizing Key	Unshielded	Gold	2	0.1 in	2.54 mm	457.2 mm	1.5 ft
3M Electronic Specialty M3CCK-1418R			Socket to Socket	0.05 in	1.27 mm	14	IDC	30 Áin	0.76 Ám	Polarizing Key	Unshielded	Gold	2	0.1 in	2.54 mm	457.2 mm	1.5 ft	Multiple Ribbon
3M Electronic Specialty M3CCK-6040K	1.02 m	3.34 ft	Socket to Socket	0.05 in	1.27 mm	60	IDC	30 Áin	0.76 Ám	Polarizing Key	Unshielded	Gold	2	0.1 in	2.54 mm			Multiple Twisted Pair (Flat)
3M Electronic Specialty M3CCK-2418J			Socket to Socket	0.05 in	1.27 mm	24	IDC	30 Áin	0.76 Ám	Polarizing Key	Unshielded	Gold	2	0.1 in	2.54 mm	457.2 mm	1.5 ft
3M Electronic Specialty M3CCK-1040K	1.02 m	3.34 ft	Socket to Socket	0.05 in	1.27 mm	10	IDC	30 Áin	0.76 Ám	Polarizing Key	Unshielded	Gold	2	0.1 in	2.54 mm			Multiple Twisted Pair (Flat)
3M Electronic Specialty M3CCK-6020K	508 mm	1.67 ft	Socket to Socket	0.05 in	1.27 mm	60	IDC	30 Áin	0.76 Ám	Polarizing Key	Unshielded	Gold	2	0.1 in	2.54 mm			Multiple Twisted Pair (Flat)
3M Electronic Specialty M3CCK-6018J			Socket to Socket	0.05 in	1.27 mm	60	IDC	30 Áin	0.76 Ám	Polarizing Key	Unshielded	Gold	2	0.1 in	2.54 mm	457.2 mm	1.5 ft
