MP 3-Y2 Series
Manufacturer: WIMA
Beta
⌘K
CAP FILM SUPPRESSION Y2 0.01UF 1000VDC/250VAC PAPER 20%( 19 X 5 X 13MM) RADIAL 15MM 110°C BULK
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Lead Spacing | Lead Spacing | Ratings | Applications | Voltage Rating - DC | Voltage Rating - DC | Voltage Rating - AC | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Package / Case | Mounting Type | Tolerance | Features | Capacitance | Termination | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
-40 C | 110 °C | Metallized Paper | 15 mm | 0.591 in | Y2 | EMI RFI Suppression | 1 kV | 1 kVDC | 250 V | 0.512 " | 13 mm | Radial | Through Hole | 20 % | Low ESR | 10000 pF | PC Pins | 19 mm | 0.748 in | 0.197 " | 5 mm |
