SMSTBA Series
Manufacturer: Phoenix Contact
Beta
⌘K
PLUGGABLE TERMINAL BLOCKS 22 POS 5.08MM PITCH THROUGH HOLE HEADER
| Part | Material Flammability Rating | Insulation Height | Insulation Height | Contact Tail Length | Contact Tail Length | Housing Material | Contact Mating Finish | Type | Number of Positions | Current - IEC | Voltage - UL | Header Orientation | Mounting Type | Pitch | Pitch | Positions Per Level | Termination Style | Number of Levels | Voltage - IEC | Color | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | UL94 V-0 | 14.8 mm | 0.583 " | 0.138 in | 3.5 mm | Polyamide (PA) Nylon | Tin | Header Male Pins Shrouded (4 Side) | 22 | 12 A | 300 V | 45 ° | Through Hole | 5.08 mm | 0.2 in | 22 | Solder | 1 | 630 V | Green | |||
Phoenix Contact | UL94 V-0 | 14.8 mm | 0.583 " | 0.138 in | 3.5 mm | Polyamide (PA) Nylon | Tin | Header Male Pins Shrouded (4 Side) | 13 | 12 A | 300 V | Through Hole | 5 mm | 0.197 in | 13 | Solder | 1 | 320 V | Green | Copper Alloy | -40 C | 100 °C | |
Phoenix Contact | UL94 V-0 | 14.8 mm | 0.583 " | 0.138 in | 3.5 mm | Polyamide (PA) Nylon | Tin | Header Male Pins Shrouded (4 Side) | 20 | 12 A | 300 V | 45 ° | Through Hole | 5.08 mm | 0.2 in | 20 | Solder | 1 | 630 V | Green |
