LED Power Supplies 12W 230Vin 24Vout 0-500mA
LED Power Supplies 12W 230Vin 24Vout 0-500mA
| Part | Mounting Type | Efficiency | Features | Voltage - Output | Voltage - Input (Max) [Max] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Power (Watts) | Termination Style | Number of Outputs | Voltage - Isolation | Voltage - Input (Min) [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Topology | Ratings | Current - Output (Max) [Max] | Approval Agency | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Recom Power | Chassis Mount | 78 % | OTP OVP SCP | 12 V | 264 VAC | 1.97 " 50 mm | 5.04 in 128 mm | 0.51 in 13 mm | 12 W | Terminal Block | 1 | 3750 VDC | 198 VAC | -20 ░C | 50 °C | AC DC Converter | IP20 | 1 A | CB CE ENEC | Constant Voltage |
 Recom Power | Chassis Mount | 80 % | OTP OVP SCP | 24 V | 264 VAC | 1.97 " 50 mm | 5.04 in 128 mm | 0.51 in 13 mm | 12 W | Terminal Block | 1 | 3750 VDC | 198 VAC | -20 ░C | 50 °C | AC DC Converter | IP20 | 500 mA | CB CE ENEC | Constant Voltage |
