055456 Series
Manufacturer: Molex
Beta
⌘K
CONN HEADER SMD R/A 5POS 1.25MM
| Part | Contact Material | Material Flammability Rating | Features | Connector Type | Fastening Type | Termination | Contact Finish - Post | Insulation Material | Number of Positions Loaded | Contact Type | Mounting Type | Pitch - Mating | Pitch - Mating | Number of Rows | Insulation Height | Insulation Height | Style | Insulation Color | Contact Length - Mating | Contact Length - Mating | Shrouding | Contact Shape | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | Brass | UL94 V-0 | Board Guide Solder Retention | Header | Push-Pull | Solder | Tin | Nylon Polyamide (PA) | All | Male Pin | Surface Mount Right Angle | 1.25 mm | 0.049 in | 1 | 0.177 in | 4.5 mm | Board to Cable/Wire | Natural | 0.11 in | 2.79 mm | Shrouded - 4 Wall | Square | |
Molex | Brass | UL94 V-0 | Solder Retention | Header | Push-Pull | Solder | Tin | Nylon Polyamide (PA) | All | Male Pin | Surface Mount Right Angle | 1.25 mm | 0.049 in | 1 | 0.177 in | 4.5 mm | Board to Cable/Wire | Natural | 0.11 in | 2.79 mm | Shrouded - 4 Wall | Square | 13 |
 Molex | Brass | UL94 V-0 | Solder Retention | Header | Push-Pull | Solder | Tin | Nylon Polyamide (PA) | All | Male Pin | Surface Mount Right Angle | 1.25 mm | 0.049 in | 1 | 0.177 in | 4.5 mm | Board to Cable/Wire | Natural | 0.11 in | 2.79 mm | Shrouded - 4 Wall | Square | 11 |
 Molex | Brass | UL94 V-0 | Solder Retention | Header | Push-Pull | Solder | Tin | Nylon Polyamide (PA) | All | Male Pin | Surface Mount Right Angle | 1.25 mm | 0.049 in | 1 | 0.177 in | 4.5 mm | Board to Cable/Wire | Natural | 0.11 in | 2.79 mm | Shrouded - 4 Wall | Square | 4 |
Molex | Brass | UL94 V-0 | Board Guide Solder Retention | Header | Push-Pull | Solder | Tin | Nylon Polyamide (PA) | All | Male Pin | Surface Mount Right Angle | 1.25 mm | 0.049 in | 1 | 0.177 in | 4.5 mm | Board to Cable/Wire | Natural | 0.11 in | 2.79 mm | Shrouded - 4 Wall | Square | 20 |
