807-030 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 30POS 0.156
| Part | Termination Rows | Material - Insulation | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Read Out | Card Type | Pitch | Pitch | Number of Positions/Bay/Row | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Number of Positions | Number of Rows | Gender | Contact Material | Mounting Type | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Termination Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Wire Wrap | 125 °C | -40 C | 0.25 Ám | 10 Áin | Single | Non Specified - Single Edge | 3.96 mm | 0.156 in | 30 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | 30 | 1 | Female | Copper Alloy | Through Hole | Green | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Solder | 125 °C | -40 C | 0.25 Ám | 10 Áin | Dual | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 30 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | 60 | Female | Copper Alloy | Right Angle Through Hole | Green | Flush Mount M3 Threaded Insert Top Opening | 2 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder | 125 °C | -40 C | Single | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 15 | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | 30 | Female | Copper Alloy | Right Angle Through Hole | Green | 2 | 2 | |||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Wire Wrap | 125 °C | -40 C | Dual | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 15 | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | 30 | Female | Copper Alloy | Through Hole | Green | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 2 | 2 | ||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Solder | 125 °C | -40 C | 0.25 Ám | 10 Áin | Dual | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 30 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | 60 | Female | Copper Alloy | Right Angle Through Hole | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 2 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder | 125 °C | -40 C | 0.25 Ám | 10 Áin | Dual | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 15 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | 30 | Female | Copper Alloy | Through Hole | Green | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 2 | 2 | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Solder | 125 °C | -40 C | Single | Non Specified - Single Edge | 3.96 mm | 0.156 in | 30 | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | 30 | 1 | Female | Copper Alloy | Right Angle Through Hole | Green | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder | 125 °C | -40 C | 0.25 Ám | 10 Áin | Dual | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 15 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | 30 | Female | Copper Alloy | Through Hole | Green | 2 | 2 | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Solder | 125 °C | -40 C | 0.25 Ám | 10 Áin | Single | Non Specified - Single Edge | 3.96 mm | 0.156 in | 30 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | 30 | 1 | Female | Copper Alloy | Through Hole | Green | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Wire Wrap | 125 °C | -40 C | 0.25 Ám | 10 Áin | Dual | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 15 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | 30 | Female | Copper Alloy | Through Hole | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 2 | 2 |
