TLJ Series

Catalog

TANTALUM CAPACITORS - SOLID SMD 10V 47UF 20% ESR=1500

Part	Tolerance	Type	ESR (Equivalent Series Resistance)	Features	Mounting Type	Manufacturer Size Code	Voltage - Rated	Height - Seated (Max) [Max]	Height - Seated (Max)	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Package / Case	Capacitance	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]
KYOCERA AVX TLJG476M010R1500	20 %	Molded	1.5 Ohm	General Purpose	Surface Mount	G	10 V	0.059 "	1.5 mm	0.063 "	0.126 "	3.2 mm	1.6 mm	1206 (3216 Metric)	47 µF	-55 C	125 °C
KYOCERA AVX TLJR156M010R2000	20 %	Molded	2 Ohms	General Purpose	Surface Mount	R	10 V			0.051 in	0.081 in	2.05 mm	1.3 mm	0805	15 µF	-55 C	125 °C	1.2 mm	0.047 "
KYOCERA AVX TLJR476M010S3200
KYOCERA AVX TLJH157M006R0900	20 %	Molded	900 mOhm	General Purpose	Surface Mount	H	6.3 VDC	0.059 "	1.5 mm	0.11 "	0.138 in	3.5 mm	2.8 mm	1210 1411 (3528 Metric)	150 µF	-55 C	125 °C
KYOCERA AVX TLJG227M004R3000	20 %	Molded	3 Ohm	General Purpose	Surface Mount	G	4 V	0.059 "	1.5 mm	0.063 "	0.126 "	3.2 mm	1.6 mm	1206 (3216 Metric)	220 µF	-55 C	125 °C
KYOCERA AVX TLJA107M006R0500	20 %	Molded	500 mOhms	General Purpose	Surface Mount	A	6.3 VDC	0.071 in		0.063 "	0.126 "	3.2 mm	1.6 mm	1206 (3216 Metric)	100 µF	-55 C	125 °C			1.8 mm
