B07D93 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

B07D939BC1-0297 = RELAY.

Part	Coil Resistance	Contact Form	Release Time	Must Release Voltage	Seal Rating	Coil Type	Contact Material	Operate Time	Coil Current	Mounting Type	Coil Voltage	Must Operate Voltage	Contact Rating (Current)	Termination Style	Relay Type	Operating Temperature [Min]	Operating Temperature [Max]	Grade
TE Connectivity AMP Connectors 1617005-3	300 Ohms	DPDT (2 Form C)	10 ms	1.8 VDC	Sealed - Hermetically	Non Latching	Silver Cadmium Oxide (AgCdO)	10 ms	88.3 mA	Through Hole	26.5 VDC	13 VDC	10 A	PC Pin	General Purpose	-65 ░C	125 °C
TE Connectivity AMP Connectors 1617005-2	300 Ohms	DPDT (2 Form C)	10 ms	1.8 VDC	Sealed - Hermetically	Non Latching	Silver Cadmium Oxide (AgCdO)	10 ms	88.3 mA	Through Hole	26.5 VDC	13 VDC	10 A	PC Pin	General Purpose	-65 ░C	125 °C
TE Connectivity AMP Connectors B07D932BA2-0350		DPDT (2 Form C)	15 ms	1.8 VDC	Sealed - Hermetically	Non Latching	Silver Cadmium Oxide (AgCdO)	15 ms		Chassis Mount		3.25 VDC	10 A	Solder Hook	General Purpose	-65 ░C	125 °C	Military
TE Connectivity AMP Connectors 9-1617527-1	300 Ohms	DPDT (2 Form C)	10 ms	1.8 VDC	Sealed - Hermetically	Non Latching	Silver Cadmium Oxide (AgCdO)	10 ms	88.3 mA	Chassis Mount	26.5 VDC	13 VDC	10 A	Solder Hook	General Purpose	-65 ░C	125 °C
TE Connectivity AMP Connectors B07D934BB2-0119	75 Ohms	DPDT (2 Form C)	10 ms	0.9 VDC	Sealed - Hermetically	Non Latching	Silver Cadmium Oxide (AgCdO)	10 ms	160 mA	Through Hole	12 VDC	6.5 VDC	10 A	PC Pin	General Purpose	-65 ░C	125 °C
TE Connectivity AMP Connectors 1617005-1	7600 Ohms	DPDT (2 Form C)	10 ms	9 VDC	Sealed - Hermetically	Non Latching	Silver Cadmium Oxide (AgCdO)	10 ms	15.8 mA	Through Hole	120 VDC	66 VDC	10 A	PC Pin	General Purpose	-65 ░C	125 °C
TE Connectivity AMP Connectors 5-1617004-0	7600 Ohms	DPDT (2 Form C)	10 ms	9 VDC	Sealed - Hermetically	Non Latching	Silver Cadmium Oxide (AgCdO)	10 ms	15.8 mA	Through Hole	120 VDC	66 VDC	10 A	PC Pin	General Purpose	-65 ░C	125 °C
TE Connectivity AMP Connectors 4-1617004-6	300 Ohms	DPDT (2 Form C)	10 ms	1.8 VDC	Sealed - Hermetically	Non Latching	Silver Cadmium Oxide (AgCdO)	10 ms	88.3 mA	Through Hole	26.5 VDC	13 VDC	10 A	PC Pin	General Purpose	-65 ░C	125 °C
TE Connectivity AMP Connectors B07D932BC2-0348	300 Ohms	DPDT (2 Form C)	15 ms	2.3 VDC	Sealed - Hermetically	Non Latching	Silver Cadmium Oxide (AgCdO)	15 ms	88.3 mA	Chassis Mount	26.5 VDC	13 VDC	10 A	Solder Hook	General Purpose	-65 ░C	125 °C	Military
TE Connectivity AMP Connectors B07D932BZ2-0358	170 Ohms	DPDT (2 Form C)	15 ms	1.15 VDC	Sealed - Hermetically	Non Latching	Silver Cadmium Oxide (AgCdO)	15 ms	105.9 mA	Chassis Mount	18 VDC	9.7 VDC	10 A	Solder Hook	General Purpose	-65 ░C	125 °C
