6830 Series

Catalog

WIRE, HOOK UP, ECOGEN™ ECOWIRE® PLUS, 300V, MPPE, ORANGE, 12 AWG, 3.08 MM², 1000 FT

Part	Conductor Material	Jacket Color	Cable Type	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Wire Gauge	Jacket (Insulation) Material	Conductor Strand [custom]	Conductor Strand [custom]	Operating Temperature [Min]	Operating Temperature [Max]	Length	Length	Voltage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length [x]	Length [x]
ALPHA WIRE 6830 OR001	Copper Bare	Orange	Hook-Up	0.38 mm	0.015 in	12 AWG	Polyphenylene Ether (PPE)	19	25 AWG	-40 C	110 °C	304.8 m	1000 ft	300 VDC	3.05 mm	0.12 in
ALPHA WIRE 6830 RD005	Copper Bare	Red	Hook-Up	0.38 mm	0.015 in	12 AWG	Polyphenylene Ether (PPE)	19	25 AWG	-40 C	110 °C			300 VDC	3.05 mm	0.12 in	100 ft	30.5 m
ALPHA WIRE 6830 YL001	Copper Bare	Yellow	Hook-Up	0.38 mm	0.015 in	12 AWG	Polyphenylene Ether (PPE)	19	25 AWG	-40 C	110 °C	304.8 m	1000 ft	300 VDC	3.05 mm	0.12 in
ALPHA WIRE 6830 OR005	Copper Bare	Orange	Hook-Up	0.38 mm	0.015 in	12 AWG	Polyphenylene Ether (PPE)	19	25 AWG	-40 C	110 °C			300 VDC	3.05 mm	0.12 in	100 ft	30.5 m
ALPHA WIRE 6830 GY005	Copper Bare	Green Yellow Stripe	Hook-Up	0.38 mm	0.015 in	12 AWG	Polyphenylene Ether (PPE)	19	25 AWG	-40 C	110 °C			300 VDC	3.05 mm	0.12 in	100 ft	30.5 m
ALPHA WIRE 6830 BR005	Copper Bare	Brown	Hook-Up	0.38 mm	0.015 in	12 AWG	Polyphenylene Ether (PPE)	19	25 AWG	-40 C	110 °C			300 VDC	3.05 mm	0.12 in	100 ft	30.5 m
ALPHA WIRE 6830 BL001	Copper Bare	Blue	Hook-Up	0.38 mm	0.015 in	12 AWG	Polyphenylene Ether (PPE)	19	25 AWG	-40 C	110 °C	304.8 m	1000 ft	300 VDC	3.05 mm	0.12 in
ALPHA WIRE 6830 BL005	Copper Bare	Blue	Hook-Up	0.38 mm	0.015 in	12 AWG	Polyphenylene Ether (PPE)	19	25 AWG	-40 C	110 °C			300 VDC	3.05 mm	0.12 in	100 ft	30.5 m
ALPHA WIRE 6830 BK001	Copper Bare	Black	Hook-Up	0.38 mm	0.015 in	12 AWG	Polyphenylene Ether (PPE)	19	25 AWG	-40 C	110 °C	304.8 m	1000 ft	300 VDC	3.05 mm	0.12 in
ALPHA WIRE 6830 WH005	Copper Bare	White	Hook-Up	0.38 mm	0.015 in	12 AWG	Polyphenylene Ether (PPE)	19	25 AWG	-40 C	110 °C			300 VDC	3.05 mm	0.12 in	100 ft	30.5 m
