1377175 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

CONN QC RCPT 12-13AWG 0.250

Part	Tab Width	Tab Width	Contact Material	Terminal Type	Insulation Diameter [diameter]	Insulation Diameter [diameter]	Tab Thickness	Tab Thickness	Contact Finish	Gender	Color	Wire Gauge [Min]	Wire Gauge [Max]	Insulation	Mounting Type	Termination	Material	Note	For Use With/Related Products	For Use With/Related Products	For Use With/Related Products	Style	Terminal Size	Terminal Size	Number of Positions	Stacking Direction	Length - Overall [x]	Length - Overall	Tab Length	Tab Length	Length - Overall [x]	Tab Length
TE Connectivity Raychem Cable Protection 1-1377175-5	6.35 mm	0.25 in	Brass	Standard	3.99 mm	0.157 in	0.032 in	0.81 mm	Tin	Female	Blue	12 AWG	13 AWG	Fully Insulated	Free Hanging (In-Line)	Crimp
TE Connectivity Raychem Cable Protection 2-1377175-9				Disconnect Quick Connect						Female Receptacle	Natural				Free Hanging (In-Line)		Nylon	Contacts Not Included	0.25 in	Quick Connects	6.35 mm	Housing	6.35 mm	0.25 in	1
TE Connectivity Raychem Cable Protection 3-1377175-0											Natural				Free Hanging (In-Line)		Polyamide (PA66) Nylon 6/6	Contacts Not Included				Housing			2	Side to Side
TE Connectivity Raychem Cable Protection 4-1377175-4				Disconnect Quick Connect						Male Tab	Natural				Free Hanging (In-Line)		Polyamide (PA66) Nylon 6/6	Contacts Not Included	0.25 in	Quick Connects	6.35 mm	Housing	6.35 mm	0.25 in	2	Side to Side
TE Connectivity Raychem Cable Protection 1377175-2	4.75 mm	0.187 in	Brass	Standard			0.032 in	0.81 mm	Tin	Female	Blue			Non-Mating End Insulated	Free Hanging (In-Line)	Crimp											0.862 in	21.9 mm	6.35 mm	0.25 in
TE Connectivity Raychem Cable Protection 4-1377175-8				Disconnect Quick Connect						Male Tab	Natural				Free Hanging (In-Line)		Nylon	Contacts Not Included	0.25 in	Quick Connects	6.35 mm	Housing	6.35 mm	0.25 in	6	Top to Bottom and Side to Side
TE Connectivity Raychem Cable Protection 1-1377175-2	6.35 mm	0.25 in	Brass	Standard	3.4 mm	0.134 in	0.032 in	0.81 mm	Tin	Female	Red	16 AWG	17 AWG	Fully Insulated	Free Hanging (In-Line)	Crimp											0.85 "				21.59 mm
TE Connectivity Raychem Cable Protection 1377175-8	7.92 mm	0.312 in	Brass	Standard			0.03 in	0.76 mm	Tin	Female	Blue			Non-Mating End Insulated	Free Hanging (In-Line)	Crimp											0.98 in		9.65 mm	0.38 in	24.89 mm
TE Connectivity Raychem Cable Protection 3-1377175-3	6.35 mm	0.25 in	Brass	Standard			0.032 in	0.81 mm	Tin	Female		10 AWG	12 AWG	Non-Insulated	Free Hanging (In-Line)	Crimp											0.791 in			7.7 mm	20.09 mm	0.303 in
TE Connectivity Raychem Cable Protection 1-1377175-6	6.35 mm	0.25 in	Brass	Standard	3.99 mm	0.157 in	0.032 in	0.81 mm	Tin	Female	Blue			Fully Insulated	Free Hanging (In-Line)	Crimp
