Modular Connectors / Ethernet Connectors MAGJACK 1x1 5G 100W
Modular Connectors / Ethernet Connectors MAGJACK 1x1 5G 100W
| Part | Shield Material | Housing Material | Contact Finish Thickness | Contact Finish Thickness | Number of Ports | Applications | Termination | Connector Type | Tab Direction | Features | Shielding | Number of Rows | LED Color | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Orientation | Contact Material | Number of Cores per Jack | Height Above Board [z] | Height Above Board [z] | Contact Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | Copper Alloy | Polyamide (PA) Nylon | 50 µin | 1.27 µm | 1 | 10/100/1000 Base-T AutoMDIX | Solder | RJ45 | Up | Board Guide | EMI Finger Shielded | 1 | Green Orange Yellow | Through Hole | 85 °C | -40 C | 90 ° | Copper Alloy | 8 | 0.536 in | 13.61 mm | Gold |
 Bel Fuse Inc. | 1 | 5G Base-T AutoMDIX Power over Ethernet (PoE) | Solder | RJ45 | Up | Board Guide | EMI Finger Shielded | 1 | Green Orange Yellow | Through Hole | 85 °C | -40 C | 90 ° | Phosphor Bronze | 0.536 in | 13.61 mm | Gold | |||||
 Bel Fuse Inc. | Copper Alloy | Polyamide (PA46) Nylon 4/6 | 50 µin | 1.27 µm | 1 | 10/100/1000 Base-T AutoMDIX | Solder | RJ45 | Up | Board Guide | EMI Finger Shielded | 1 | Green Yellow - Green | Through Hole | 70 °C | 0 °C | 90 ° | Copper Alloy | 12 | 0.536 in | 13.61 mm | Gold |
 Bel Fuse Inc. | Copper Alloy | Polyamide (PA) Nylon | 50 µin | 1.27 µm | 1 | 10/100 Base-T AutoMDIX Power over Ethernet+ (PoE+) | Solder | RJ45 | Up | Board Guide | EMI Finger Shielded | 1 | Green Orange Yellow | Through Hole | 85 °C | -40 C | 90 ° | Copper Alloy | 0.536 in | 13.61 mm | Gold | |
 Bel Fuse Inc. | 1 | 5G Base-T AutoMDIX Power over Ethernet (PoE) | Solder | RJ45 | Up | Board Guide | EMI Finger Shielded | 1 | Green Orange Yellow | Through Hole | 85 °C | -40 C | 90 ° | Phosphor Bronze | 0.536 in | 13.61 mm | Gold | |||||
 Bel Fuse Inc. | 4 | 10/100/1000 Base-T AutoMDIX | Solder | RJ45 | Up | Board Guide | EMI Finger Shielded | 1 | Yellow - Green | Through Hole | 70 °C | 0 °C | 90 ° | Copper Alloy | 12 | 0.535 in | 13.59 mm | Gold |
