395-118 Series
Manufacturer: EDAC Inc.
Beta
⌘K
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Material - Insulation | Termination Rows [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Mounting Type | Contact Finish | Termination | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Color | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Features | Number of Positions/Bay/Row [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Contact Type | Pitch | Pitch | Number of Positions | Read Out |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | Board Edge Straddle Mount | Gold | Solder | 0.25 Ám | 10 Áin | Copper Alloy | Black | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender | 59 | -40 C | 105 ░C | Female | Cantilever | 0.1 " | 2.54 mm | 118 | Dual |
 EDAC Inc. | Polyester Thermoplastic | 2 | 4-40 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | Right Angle Through Hole | Gold | Solder | 0.25 m 0.25 Ám | 10 in 10 Áin | Copper Alloy | Black | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | 59 | -40 C | 105 ░C | Female | Cantilever | 0.1 " | 2.54 mm | 118 | Dual | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.156 " | 3.96 mm | Non Specified - Dual Edge | Through Hole | Gold | Solder | 0.25 Ám | 10 Áin | Copper Alloy | Black | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 59 | -40 C | 105 ░C | Female | Cantilever | 0.1 " | 2.54 mm | 118 | Dual | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.156 " | 3.96 mm | Non Specified - Dual Edge | Through Hole | Gold | Wire Wrap | 0.25 Ám | 10 Áin | Copper Alloy | Black | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 59 | -40 C | 105 ░C | Female | Cantilever | 0.1 " | 2.54 mm | 118 | Dual | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 4-40 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | Right Angle Through Hole | Gold | Solder | 0.25 Ám | 10 Áin | Copper Alloy | Black | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | 59 | -40 C | 105 ░C | Female | Cantilever | 0.1 " | 2.54 mm | 118 | Dual | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | M3 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | Right Angle Through Hole | Gold | Solder | 0.25 Ám | 10 Áin | Copper Alloy | Black | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 59 | -40 C | 105 ░C | Female | Cantilever | 0.1 " | 2.54 mm | 118 | Dual | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.128 " | 3.25 mm | Non Specified - Dual Edge | Board Edge Straddle Mount | Gold | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Copper Alloy | Black | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender | 59 | -40 C | 105 ░C | Female | Cantilever | 0.1 " | 2.54 mm | 118 | Dual | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.128 " | 3.25 mm | Non Specified - Dual Edge | Through Hole | Gold | Solder | 0.25 Ám | 10 Áin | Copper Alloy | Black | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 59 | -40 C | 105 ░C | Female | Cantilever | 0.1 " | 2.54 mm | 118 | Dual | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 4-40 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | Through Hole | Gold | Solder | 0.25 Ám | 10 Áin | Copper Alloy | Black | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | 59 | -40 C | 105 ░C | Female | Cantilever | 0.1 " | 2.54 mm | 118 | Dual | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | Through Hole | Gold | Solder | 0.25 Ám | 10 Áin | Copper Alloy | Black | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | 59 | -40 C | 105 ░C | Female | Cantilever | 0.1 " | 2.54 mm | 118 | Dual |
