OSTVN15 Series
Manufacturer: On Shore Technology Inc.
Beta
⌘K
TERM BLK 15P SIDE ENT 2.54MM PCB
| Part | Contact Material - Plating | Clamp Material - Plating | Operating Temperature [Min] | Operating Temperature [Max] | Housing Material | Screw Thread | Screw Material - Plating | Torque - Screw | Torque - Screw | Color | Wire Termination | Voltage | Pitch | Pitch | Number of Levels | Mounting Type | Positions Per Level | Mating Orientation | Current |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 On Shore Technology Inc. | Brass | Brass | -30 ░C | 105 ░C | Thermoplastic | M1.6 | Steel - Zinc Plated | 1.3 Lb-In | 0.15 Nm | Green | Screw - Rising Cage Clamp | 150 V | 0.1 " | 2.54 mm | 1 | Through Hole | 15 | Horizontal with Board | 6 A |
