W25Q20 Series

Catalog

IC FLASH 2MBIT SPI/QUAD 104MHZ

Part	Clock Frequency	Memory Interface	Access Time	Write Cycle Time - Word, Page [custom]	Write Cycle Time - Word, Page [custom]	Voltage - Supply [Max]	Voltage - Supply [Min]	Memory Type	Memory Organization	Technology	Memory Size	Memory Format	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case	Package / Case	Mounting Type	Write Cycle Time - Word, Page
Winbond Electronics W25Q20EWNB02	104 MHz	SPI - Quad I/O	6 ns	30 µs	800 µs	1.95 V	1.65 V	Non-Volatile	256K x 8	FLASH - NOR	2 Gbit	FLASH
Winbond Electronics W25Q20EWSNIG	104 MHz	SPI - Quad I/O				1.95 V	1.65 V	Non-Volatile	256K x 8	FLASH - NOR	2 Gbit	FLASH	8-SOIC	85 C	-40 ¯C	0.154 in	8-SOIC	3.9 mm	Surface Mount	800 µs
Winbond Electronics W25Q20EWUXAE	104 MHz	SPI - Quad I/O	6 ns	30 µs	800 µs	1.95 V	1.65 V	Non-Volatile	256K x 8	FLASH - NOR	2 Gbit	FLASH	8-USON (2x3)	105 °C	-40 °C		8-UFDFN Exposed Pad		Surface Mount
Winbond Electronics W25Q20EWNB03	104 MHz	SPI - Quad I/O	6 ns	30 µs	800 µs	1.95 V	1.65 V	Non-Volatile	256K x 8	FLASH - NOR	2 Gbit	FLASH
Winbond Electronics W25Q20RLXHJQ TR	104 MHz	SPI - Quad I/O							256K x 8		2 Gbit	FLASH
Winbond Electronics W25Q20EWSVIG TR	104 MHz	SPI - Quad I/O				1.95 V	1.65 V	Non-Volatile	256K x 8	FLASH - NOR	2 Gbit	FLASH	8-VSOP	85 C	-40 ¯C	0.154 in	8-SOIC	3.9 mm	Surface Mount	800 µs
Winbond Electronics W25Q20EWUXSE	104 MHz	SPI - Quad I/O	6 ns	30 µs	800 µs	1.95 V	1.65 V	Non-Volatile	256K x 8	FLASH - NOR	2 Gbit	FLASH	8-USON (2x3)				8-UFDFN Exposed Pad		Surface Mount
Winbond Electronics W25Q20EWSNIG TR	104 MHz	SPI - Quad I/O				1.95 V	1.65 V	Non-Volatile	256K x 8	FLASH - NOR	2 Gbit	FLASH	8-SOIC	85 C	-40 ¯C	0.154 in	8-SOIC	3.9 mm	Surface Mount	800 µs
Winbond Electronics W25Q20CLSNIG TR	104 MHz	SPI - Quad I/O	8 ns			3.6 V	2.3 V	Non-Volatile	256K x 8	FLASH - NOR	2 Gbit	FLASH	8-SOIC	85 C	-40 ¯C	0.154 in	8-SOIC	3.9 mm	Surface Mount	800 µs
Winbond Electronics W25Q20EWUXIE TR	104 MHz	SPI - Quad I/O				1.95 V	1.65 V	Non-Volatile	256K x 8	FLASH - NOR	2 Gbit	FLASH	8-USON (2x3)	85 C	-40 ¯C		8-UFDFN Exposed Pad		Surface Mount	800 µs
