FLB Series

Catalog

FILM CAPACITORS 440V 10% 3 X 137.0 U F

Part	Applications	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Dielectric Material	Voltage Rating - AC	Package / Case	Lead Spacing	Lead Spacing	Tolerance	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Size / Dimension [diameter]	Size / Dimension [diameter]	Capacitance	Termination	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KYOCERA AVX FLBE6L1376K03	3 Phase Power Factor Correction (PFC)	202 mm	7.953 in	Polypropylene (PP) Metallized	440 V	Can Radial	0.63 in	16 mm	10 %	85 °C	-40 C	Chassis Mount	4.567 "	116 mm	137 µF	Terminal Block
KYOCERA AVX FLBA6N0246K03	3 Phase Power Factor Correction (PFC)	202 mm	7.953 in	Polypropylene (PP) Metallized	660 V	Can Radial			10 %	85 °C	-40 C	Chassis Stud Mount	3.346 "	85 mm	24.4 µF	Terminal Block
KYOCERA AVX FLBD6J0776K03	3 Phase Power Factor Correction (PFC)			Polypropylene (PP) Metallized	525 V	Can Radial	0.63 in	16 mm	10 %	85 °C	-40 C	Chassis Mount	4.567 "	116 mm	77 µF	Terminal Block	6.378 in	162 mm
