TRA806 Series

Catalog

RF ANT 850MHZ/900MHZ DOME NMO

Part	Gain	Termination	Power - Max [Max]	Number of Bands	Height (Max) [z]	Height (Max) [z]	Applications	Frequency Group	RF Family/Standard	Mounting Type	Frequency (Center/Band)	VSWR	Frequency Range [Min]	Frequency Range [Max]	Frequency Range	Antenna Type
TE Connectivity AMP Connectors TRA806-17103	3 dBi 4.2 dBi 4.4 dBic 5.1 dBic 5.8 dB 5.9 dBi	NMO	100 W	7	2.3 in	58.42 mm	AMPS DCS GPS GSM PCS UMTS	Wide Band	Cellular General ISM	Base Mount	1.575 GHz 1.8 GHz 1.9 GHz 2.1 GHz 2.4 GHz 850 MHz 900 MHz	2 2.5	1.71 GHz 2.4 GHz 806 MHz	2.17 GHz 2.5 GHz 960 MHz	1.575 GHz	Dome
TE Connectivity AMP Connectors TRA806-17103P	3 dBi 4.2 dBi 4.4 dBic 5.1 dBic 5.8 dB 5.9 dBi	N Type Female	100 W	7	2.3 in	58.42 mm	AMPS DCS GPS GSM PCS UMTS	Wide Band	Cellular General ISM	Panel Mount	1.575 GHz 1.8 GHz 1.9 GHz 2.1 GHz 2.4 GHz 850 MHz 900 MHz	2 2.5	1.71 GHz 2.4 GHz 806 MHz	2.17 GHz 2.5 GHz 960 MHz	1.575 GHz	Dome
TE Connectivity AMP Connectors TRA806-17103	3 dBi 4.2 dBi 4.4 dBic 5.1 dBic 5.8 dB 5.9 dBi	NMO	100 W	7	2.3 in	58.42 mm	AMPS DCS GPS GSM PCS UMTS	Wide Band	Cellular General ISM	Base Mount	1.575 GHz 1.8 GHz 1.9 GHz 2.1 GHz 2.4 GHz 850 MHz 900 MHz	2 2.5	1.71 GHz 2.4 GHz 806 MHz	2.17 GHz 2.5 GHz 960 MHz	1.575 GHz	Dome
TE Connectivity AMP Connectors TRA806-17103P	3 dBi 4.2 dBi 4.4 dBic 5.1 dBic 5.8 dB 5.9 dBi	N Type Female	100 W	7	2.3 in	58.42 mm	AMPS DCS GPS GSM PCS UMTS	Wide Band	Cellular General ISM	Panel Mount	1.575 GHz 1.8 GHz 1.9 GHz 2.1 GHz 2.4 GHz 850 MHz 900 MHz	2 2.5	1.71 GHz 2.4 GHz 806 MHz	2.17 GHz 2.5 GHz 960 MHz	1.575 GHz	Dome
