174-E15 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB RCPT 15POS R/A SLDR
| Part | Dielectric Material | Operating Temperature [Max] | Operating Temperature [Min] | Color | Material Flammability Rating | Contact Type | Contact Finish | Backset Spacing | Backset Spacing | Features | Number of Rows [custom] | Number of Positions | Contact Finish Thickness | Connector Type | Current Rating (Amps) | Termination | Flange Feature | Mounting Type | Connector Style | Shell Size, Connector Layout | Contact Material | Shell Material, Finish | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | White | UL94 V-0 | Signal | Gold | 9.4 mm | 0.37 in | Mounting Brackets | 2 | 15 | Flash | Receptacle Female Sockets | 5 A | Solder | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | D-Sub | 2 | |||||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | White | UL94 V-0 | Signal | Gold | 9.4 mm | 0.37 in | 2 | 15 | Flash | Receptacle Female Sockets | 5 A | Solder | Housing/Shell (Unthreaded) | Panel Mount Right Angle Through Hole | D-Sub | 2 | Brass | Nickel Plated Steel | ||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | White | UL94 V-0 | Signal | Gold | 9.4 mm | 0.37 in | 2 | 15 | Flash | Receptacle Female Sockets | 5 A | Solder | Housing/Shell (Unthreaded) | Panel Mount Right Angle Through Hole | D-Sub | 2 | ||||||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | White | UL94 V-0 | Signal | Gold | 9.4 mm | 0.37 in | Mounting Brackets | 2 | 15 | Flash | Plug Male Pins | 5 A | Solder | Mating Side Standard Screws (4-40) | Panel Mount Right Angle Through Hole | D-Sub | 2 | Brass | Steel | Yellow Chromate Plated | ||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | White | UL94 V-0 | Signal | Gold | 9.4 mm | 0.37 in | 2 | 15 | Flash | Plug Male Pins | 5 A | Solder | Housing/Shell (Unthreaded) | Panel Mount Right Angle Through Hole | D-Sub | 2 | Steel | Yellow Chromate Plated | ||||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | White | UL94 V-0 | Signal | Gold | 9.4 mm | 0.37 in | Board Lock Grounding Indents Mounting Brackets | 2 | 15 | Flash | Plug Male Pins | 5 A | Solder | Housing/Shell | Panel Mount Right Angle Through Hole | D-Sub | 2 | Brass | Nickel Plated Steel | 4-40 | ||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | White | UL94 V-0 | Signal | Gold | 9.4 mm | 0.37 in | 2 | 15 | Flash | Receptacle Female Sockets | 5 A | Solder | Housing/Shell (Unthreaded) | Panel Mount Right Angle Through Hole | D-Sub | 2 | Brass | Steel | Yellow Chromate Plated | |||
NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | White | UL94 V-0 | Signal | Gold | 9.4 mm | 0.37 in | Grounding Indents Mounting Brackets | 2 | 15 | Flash | Plug Male Pins | 5 A | Solder | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | D-Sub | 2 | Nickel Plated Steel | ||||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | White | UL94 V-0 | Signal | Gold | 9.4 mm | 0.37 in | Mounting Brackets | 2 | 15 | Flash | Receptacle Female Sockets | 5 A | Solder | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | D-Sub | 2 | Brass | Steel | Yellow Chromate Plated |
